G215HVN01.3 21.5 INCH 1920×1080 LCD Display Panel Module for AUO

Name: G215HVN01.3 21.5 INCH 1920×1080 LCD Display Panel Module for AUO
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: G215HVN01.3
Price: 300 USD
Availability: InStock

SKU: G215HVN01.3

Model: G215HVN01.3
Panel Size: 21.5 inches (diagonal)
Panel Type: a-Si TFT-LCD, LCM (VA Mode, Normally Black)
Resolution: 1920 × 1080 (FHD), 102 PPI

0.0 (0 Reviews)

0 Sold

~~$305.00~~ $300.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

G215HVN01.3 21.5 INCH 1920×1080 LCD Display Panel Module for AUO

Parameter	Specification
Brand	AUO
Model	G215HVN01.3
Panel Size	21.5 inches (diagonal)
Panel Type	a-Si TFT-LCD, LCM (VA Mode, Normally Black)
Resolution	1920 × 1080 (FHD), 102 PPI
Active Display Area	476.64 mm (W) × 268.11 mm (H)
Outline Dimensions	495.6×292.2×24.05 mm (H×V×D)
Pixel Configuration	RGB Vertical Stripe
Pixel Pitch	0.24825 mm × 0.24825 mm
Brightness	1000 cd/m² (Typical, High Brightness)
Contrast Ratio	5000:1 (Typical)
Viewing Angle	89°/89°/89°/89° (L/R/U/D, CR≥10)
Response Time	20/5 ms (Typical, Tr/Td)
Color Depth	16.7M colors (8-bit RGB)
Color Gamut	73% NTSC
Backlight	WLED, 50,000 hours lifespan, integrated driver
Interface	30-pin LVDS (2 channels, 8-bit)
Input Voltage	5.0 V (Typical)
Surface Treatment	Anti-Glare (AG), 3H hard coat
Net Weight	Approx. 1.63 kg
Operating Temperature	-20°C ~ +80°C
Storage Temperature	-20°C ~ +80°C
Compliance	RoHS Certified

Typical Applications

Outdoor Digital Signage: High-brightness displays for advertising billboards, public information screens, and outdoor kiosks visible under direct sunlight.
Industrial Automation: Factory HMI panels, production line monitors, and control terminals for manufacturing equipment requiring high reliability.
Smart Transportation: Railway station displays, subway information screens, and in-vehicle monitors for public transport systems.
Medical Equipment: Diagnostic devices, patient monitoring systems, and medical workstations needing wide viewing angles and stable performance.
Retail & Self-Service: POS systems, vending machines, and self-checkout terminals with 24/7 operation capability.
Energy & Utilities: Control room displays for power plants, substations, and mining operations operating in harsh environments.
