LS027B7DH01 Sharp 2.7 Inch 400×240 LCD Panel Screen For Industrial

Name: LS027B7DH01 Sharp 2.7 Inch 400×240 LCD Panel Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LS027B7DH01
Price: 30 USD
Availability: InStock

SKU: LS027B7DH01

Model P/N: LS027B7DH01
Diagonal Size: 2.7"
Panel Type: CG-Silicon, LCM
Resolution: 400×240, WQVGA 172PPI
Pixel Format: Rectangle

0.0 (0 Reviews)

0 Sold

~~$35.00~~ $30.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

LS027B7DH01 Sharp 2.7 Inch 400×240 LCD Panel Screen For Industrial

Parameter Category	Parameter Name	Specification	Unit
Basic Information	Model	LS027B7DH01	-
	Brand	Sharp	-
	Panel Type	Memory LCD, Reflective, Monochrome	-
	Diagonal Size	2.7	Inch
	Resolution	400 × 240	Pixels
	Display Mode	Reflective (No Backlight)	-
	Color	Monochrome ( White)	-
Optical Performance	Brightness	Reflective (Ambient Light)	-
	Contrast Ratio	High (Memory LCD)	-
	Viewing Angle	Wide	-
	Surface	Anti-glare	-
Electrical & Interface	Interface	SPI	-
	Input Voltage	5.0	V
	Consumption	50/175uW (Typ.)(display/update)	-
	Data Retention	No power required for image hold	-
Mechanical	Outline	57.6 × 38.6 × 1.35	mm
	Active Area	52.26 × 31.36	mm
	Weight	~11	g
Environment	Operating Temp	20 ~ 70	°C
	Storage Temp	-30 ~ 80	°C
