| Parameter | Specification |
|---|---|
| Display Size | 16.0 inches diagonal (406.4 mm) |
| Aspect Ratio | 4:3 (Standard square format) |
| Active Area | 324 mm (W) × 243 mm (H) |
| Resolution | 1024 × 768 pixels (XGA) |
| Display Technology | TFT LCD with LED backlight |
| Panel Type | Typically IPS (In-Plane Switching) for wide viewing angles |
| Color Depth | 16.7 million colors (24-bit true color) |
| Brightness | 250 cd/m² (typical standard); High-brightness options: 500-1000 cd/m² |
| Contrast Ratio | 800:1 (typical) |
| Response Time | 25 ms (Gray-to-Gray typical) |
| Viewing Angles | 178° horizontal, 178° vertical (CR > 10, IPS characteristic) |
| Backlight Type | White LED (edge-lit, uniform, long life) |
| Backlight Lifetime | 50,000 hours (typical to half-brightness) |
| Touch Technology | Projected Capacitive (PCAP) |
| Touch Points | 10 simultaneous touches (multi-touch support) |
| Touch Resolution | 4096 × 4096 points |
| Touch Accuracy | ±2 mm (typical) |
| Surface Hardness | 7H pencil hardness (chemically strengthened glass) |
| Surface Treatment | Anti-glare, anti-fingerprint coating |
| Optical Bonding | Optional (for enhanced readability, reduced internal reflection) |
| Front Protection | IP65 (when properly integrated into panel) NEMA 4/4X/12 compatible |
| Mounting | VESA 100×100 mm pattern (standard); panel-mount brackets optional |
| Bezel Width | Typically 20-25 mm (depending on integration method) |
| Overall Dimensions (W×H×D) | Approx. 365 mm × 295 mm × 15-30 mm (panel only, varies with backlight assembly) |
| Weight | Approx. 3.0 - 4.5 kg (6.6 - 9.9 lbs, depending on configuration) |
| Parameter | Specification |
|---|---|
| Controller Type | Integrated touch controller (typically E271-2210 or similar) |
| Touch Controller Interface | USB (standard) and/or I²C (optional) |
| Video Interface | LVDS (Low Voltage Differential Signaling) - panel interface Requires external LVDS controller board for video input |
| Video Connector | Typically 30-pin or 40-pin LVDS connector |
| Power Supply for Panel | 12 V DC (typical for backlight and logic) or 5 V DC (logic only) |
| Power Consumption (Panel only) | 15-25 W (typical, depends on brightness) |
| Backlight Driver | Integrated or external (depending on configuration) |
| Interface | Specification |
|---|---|
| Touch Output | USB 2.0 Type B connector (for connection to host PC) • Plug-and-play, HID compliant • Supports Windows, Linux, Android, macOS |
| Alternative Touch Interface | I²C (for embedded systems, Raspberry Pi, etc.) - optional |
| Video Input Requirement | Requires external LVDS controller board with inputs: • VGA (D-Sub 15-pin) • DVI • HDMI (via converter) • DisplayPort (via converter) |
| Touch Cable | Typically included: 2-meter USB cable |
| Controller Board Options | Available from various manufacturers (M.N.T., Devlin, etc.) |
| Parameter | Specification |
|---|---|
| Activation Force | Zero pressure (capacitive sensing) |
| Touch Sensitivity | Can detect through up to 10 mm glass (depending on configuration) |
| Glove Support | Yes (works with thin gloves, may require sensitivity adjustment) |
| Stylus Support | Yes (capacitive stylus) |
| Palm Rejection | Yes (advanced firmware feature) |
| Gesture Support | Full multi-touch gestures: • Pinch-to-zoom • Rotate • Swipe • Two-finger scroll |
| Response Time | < 10 ms (touch detection to USB report) |
| Report Rate | Up to 125 Hz (USB full-speed) |
| Parameter | Specification |
|---|---|
| Panel Logic Supply | 5 V DC or 3.3 V DC (depending on controller) |
| Backlight Supply | 12 V DC or 24 V DC (depends on LED configuration) |
| Backlight Current | 300-600 mA @ 12V (depending on brightness setting) |
| Total Power | 15-30 W (max, at full brightness) |
| Power Connector | Terminal block or barrel connector (depends on model) |
| Inverter | Not required (LED direct drive) |
