| Parameter | Specification |
|---|---|
| Display Size | 12.1 inches diagonal (307.3 mm) |
| Aspect Ratio | 16:10 (Widescreen) |
| Active Area | 261 mm (W) × 163 mm (H) |
| Resolution | 1280 × 800 pixels (WXGA) |
| Display Technology | TFT LCD with LED backlight |
| Panel Type | IPS (In-Plane Switching) for superior viewing angles |
| Color Depth | 16.7 million colors (24-bit true color) |
| Brightness | 800 cd/m² (typical) - High Brightness version |
| Contrast Ratio | 1000:1 (typical) |
| Response Time | 20 ms (Gray-to-Gray typical) |
| Viewing Angles | 178° horizontal, 178° vertical (CR > 10) |
| Backlight Type | White LED (edge-lit, long life) |
| Backlight Lifetime | 50,000 hours (typical to half-brightness) |
| Touch Technology | Projected Capacitive (Multi-touch, glass surface) |
| Touch Points | Up to 10 simultaneous touches |
| Touch Resolution | 4096 × 4096 points |
| Surface Hardness | 7H pencil hardness (chemically strengthened glass) |
| Front Protection | IP66 / Type 4X/6/6P/13 when properly installed NEMA 4/4X/12/13 (indoor/outdoor, washdown capable) |
| Mounting | Panel mount (front), 4× #8-32 UNC screws |
| Cutout Dimensions | 292 mm × 190 mm (11.50" × 7.48") |
| Overall Dimensions (W×H×D) | 311 mm × 209 mm × 66 mm (12.24" × 8.23" × 2.60") |
| Weight | Approx. 3.6 kg (7.9 lbs) |
| Parameter | Specification |
|---|---|
| Processor | Dual-core Intel Atom or Celeron processor (1.9 GHz typical) |
| Architecture | x86-64 (64-bit) |
| RAM | 2 GB DDR3L (soldered, non-expandable) |
| Flash Storage | 4 GB eMMC (for OS and runtime) + 8 GB SSD (user storage) |
| Expansion Storage | SD Card slot (supports up to 32 GB SDHC) |
| Graphics | Integrated Intel HD Graphics |
| Real-Time Clock | Battery-backed (CR2032, user replaceable, typical 5-year life) |
| Interface | Specification |
|---|---|
| Ethernet Port 1 | 10/100/1000BASE-T (Gigabit Ethernet, RJ45) • Primary communication port |
| Ethernet Port 2 | 10/100/1000BASE-T (Gigabit Ethernet, RJ45) • For daisy-chaining, network separation, or redundancy |
| USB Host Ports | ×3 (USB 2.0 Type A) • For keyboard, mouse, barcode scanner, flash drive |
| USB Device Port | USB 2.0 Mini-B (for PC connection, project download) |
| Serial Port | RS-232/RS-485 (isolated, configurable via terminal block) |
| Audio | Built-in speaker (1W) + 3.5mm audio output jack |
| Expansion Slot | 1× Option module slot (for additional communication interfaces) |
| Module Type | Catalog Number | Function |
|---|---|---|
| PROFIBUS DP | 2711P-RP1A or 2711P-RP1B | PROFIBUS DP master/slave |
| DeviceNet | 2711P-RN1A or 2711P-RN1B | DeviceNet scanner/adapter |
| ControlNet | 2711P-RC1A or 2711P-RC1B | ControlNet communication |
| DH+ | 2711P-RD1A or 2711P-RD1B | Data Highway Plus interface |
| Remote I/O | 2711P-RW1A or 2711P-RW1B | Remote I/O scanner |
| Parameter | Specification |
|---|---|
| Input Voltage | 24 V DC (nominal) |
| Voltage Range | 19.2 V DC to 28.8 V DC |
| Current Consumption | 1.0 A typical @ 24 V DC (24 W) 1.5 A maximum (36 W, with full brightness and peripherals) |
| Inrush Current | 15 A maximum for 20 ms |
| Connection | Removable 3-pin terminal block (24V+, 0V, FG) |
| Protection | Reverse polarity, overvoltage (up to 35 V DC), overcurrent, short-circuit |
| Isolation | 1500 V AC (input to ground) |
| Power Buffer | 10 ms power buffering (for ride-through brief power losses) |
| Parameter | Specification |
|---|---|
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Vibration Resistance | 5 - 150 Hz: 1.0 g (operating, per IEC 60068-2-6) |
| Shock Resistance | 30 g, 11 ms duration, half-sine (per IEC 60068-2-27) |
| Altitude | Up to 2000 m (6560 ft) without derating |
| Cooling | Fanless design (convection cooling) |
| Washdown Rating | Suitable for high-pressure washdown (with proper installation) |
