AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel

SKU: AA141TC01
Model P/N :AA141TC01
Diagonal Size: 14.1"
Panel Type :a-Si TFT-LCD, LCM
Resolution: 1280(RGB)×800, WXGA  107PPI
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$112.00 $110.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
1/1
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • AA141TC01 14.1inch 1280×800 Mitsubishi Lcd Panel
  • Description
The Mitsubishi AA141TC01 is a 14.1-inch a-Si TFT-LCD module engineered by Mitsubishi Electric for demanding industrial and outdoor applications . This model represents a significant advancement in industrial display technology, featuring a white LED backlight that provides exceptional brightness and long operational life while eliminating the need for an external inverter

Brand Mitsubishi
Model P/N AA141TC0
Diagonal Size 14.1"
Panel Type a-Si TFT-LCD, LCM
Resolution 1280(RGB)×800, WXGA 107PPI
Pixel Format RGB Vertical Stripe
Active Area 303.36(W)×189.6(H) mm
Bezel Opening 306.4(W)×192.6(H) mm
Outline Dim. 326(H)×216.5(V) ×16.5(D) mm
Treatment Antiglare, Hard coating (3H)
Luminance 800 cd/m² (Typ.)
Contrast Ratio 700:1 (Typ.) (TM)
View Direction 6 o'clock
Response Time 4/12 (Typ.)(Tr/Td)
Viewing Angle 80/80/80/60 (Typ.)(CR≥10)
Operating Mode TN, Normally White, Transmissive
Support Color 262K/16.7M 45% NTSC
Light Source WLED [5 strings], 100K hours, W/O Driver
Weight 1.13Kgs (Typ.)
Frame Rate 60Hz
Touch Panel Without
Interface Type LVDS (1 ch, 6/8-bit), 20 pins Connector
Power Supply 3.3V (Typ.)
Environment Operating Temperature: -20 ~ 70 °C; Storage Temperature: -20 ~ 80 °C
