AM640480G2TNQWT00H-A Ampire 5.7 inch 640×480 industrial LCD Panel Display Screen

Name: AM640480G2TNQWT00H-A Ampire 5.7 inch 640×480 industrial LCD Panel Display Screen
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: AM640480G2TNQWT00H-A
Price: 63 USD
Availability: InStock

SKU: AM640480G2TNQWT00H-A

Model: AM640480G2TNQWT00H-A (AM-640480G2TNQW-T00H-A)
Diagonal Size: 5.7 inch
Resolution: 640(RGB)×480 (VGA), 141 PPI
Display Mode: TN, Normally White, Transmissive

0.0 (0 Reviews)

0 Sold

~~$69.00~~ $63.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

AM640480G2TNQWT00H-A Ampire 5.7 inch 640×480 industrial LCD Panel Display Screen

Parameter	Specification
Brand	AMPIRE
Model	AM640480G2TNQWT00H-A (AM-640480G2TNQW-T00H-A)
Diagonal Size	5.7 inch
Resolution	640(RGB)×480 (VGA), 141 PPI
Display Mode	TN, Normally White, Transmissive
Aspect Ratio	4:3 (Landscape)
Active Area	115.2 (W) × 86.4 (H) mm
Pixel Pitch	0.18 × 0.18 mm
Outline Dimension	127 (W) × 98.43 (H) × 7.4/8.5 (D) mm (Typ./Max.)
Luminance	400 cd/m² (Typ.)
Contrast Ratio	250:1 (Typ.)
Color Depth	262K colors (6-bit RGB)
Backlight	WLED, with LED driver
Touch Panel	4-wire resistive touch (without controller)
Interface	1-channel TTL
Operating Temp.	0 ~ 70 °C
Storage Temp.	-30 ~ 80 °C
Surface Treatment	Antiglare, Hard coating (3H)
RoHS	Compliant

Applications

Industrial HMI: Human-machine interfaces for factory automation, PLCs, and control panels.
Medical Devices: Patient monitors, diagnostic equipment, and portable medical instruments.
Automotive Displays: Car PCs, navigation systems, and in-vehicle infotainment.
Point-of-Sale (POS): Retail terminals and self-service kiosks.
Portable Industrial Equipment: Handheld terminals, data loggers, and field devices.
