| Parameter | Specification |
|---|---|
| Manufacturer | Ampire Co., Ltd. (Taiwan) |
| Model | AMT98966 |
| Display Size | 12.1 inches (diagonal) |
| Resolution | 800 × 600 pixels (SVGA) |
| Active Area | 246.0 mm (W) × 184.5 mm (H) |
| Colors | 16.7 million (24-bit RGB) |
| Brightness | 300 cd/m² (typical) |
| Contrast Ratio | 500:1 |
| Viewing Angle | 70°/70°/50°/60° (L/R/U/D) — TN technology |
| Backlight | White LED edge-lit, 50,000+ hours lifespan |
| Interface | RGB (TTL) Parallel Interface – 24-bit RGB (R[7:0], G[7:0], B[7:0]) – Control signals: DE, HSYNC, VSYNC, DOTCLK |
| Touch Panel | Not included (sold as display-only); touch can be added separately |
| Power Supply | • Logic (VCC): 3.3 V ±10% • Backlight: Typ. 18–21 V @ 80–120 mA (depends on LED string) |
| Operating Temperature | -20°C to +70°C (industrial grade) |
| Module Dimensions | 268.0 mm (W) × 205.0 mm (H) × 7.0 mm (D) ✅ (matches your "268X205") |
| Bezel Cutout (Typical) | 262 mm × 199 mm |
| FPC Connector | 40-pin, 0.5 mm pitch, bottom or top entry |
| Compliance | RoHS, REACH |
