B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial

SKU: B173ZAN01.0
Model Number: B173ZAN01.0
Brand:  AUO (AU Optronics)
Diagonal Size: 17.3 inch
LCD Type: a-Si TFT-LCD, AHVA IPS, Normally Black, Transmissive
Native Resolution: 3840(RGB) × 2160, UHD 4K, 255 PPI
0.0 (0 Reviews)
0 Sold
$240.00 $237.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
1/1
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
  • Description
B173ZAN01.0 AUO 17.3 Inch 3840×2160 LCD Panel For Industrial
Specification Item Parameter Details
Model Number B173ZAN01.0
Brand AUO (AU Optronics)
Diagonal Size 17.3 inch
LCD Type a-Si TFT-LCD, AHVA IPS, Normally Black, Transmissive
Native Resolution 3840(RGB) × 2160, UHD 4K, 255 PPI
Aspect Ratio 16:9 Landscape
Pixel Pitch 0.0995 × 0.0995 mm
Active Display Area 382.12 (W) × 214.94 (H) mm
Outline Dimension 398.1 (W) × 252 (H) × 4 (D) mm
Brightness 400 cd/m² (Typ.), Min 340 cd/m²
Contrast Ratio 1000:1 (Typ.)
Viewing Angle (L/R/U/D) 89°/89°/89°/89° (CR≥10) Full Wide View
Response Time 27 ms (Typ., Tr+Td), Max 30 ms
Color Depth 16.7 Million Colors
Refresh Rate 60 Hz
Backlight WLED, Lifespan 15,000 Hours, Built-in LED Driver
Interface 4-Lane eDP 1.3, 40 Pins Connector
Input Voltage (VDD) 3.3 V Typical
Total Power Consumption 14 W (Logic + Backlight)
Surface Treatment Matte Anti-Glare, Hard Coating 3H
Glass Thickness 0.5 mm
Net Weight Max 550 g
Touch Function Non-Touch
Operating Temperature 0 ℃ ~ +50 ℃
Storage Temperature -20 ℃ ~ +60 ℃
Pixel Arrangement RGB Vertical Stripe

Application

  1. High-end 17.3" 4K creative laptops (Dell XPS 17, design/workstation notebooks)
  2. Professional graphic design, photo editing & video post-production equipment
  3. Portable industrial workstation display modules
  4. Digital drawing & color calibration professional monitors
  5. Medical portable diagnostic display terminals
  6. High-resolution portable inspection testing equipment
