AUO C070VW02 V2 7 inch 800×480 LCD Panel For Industrial

Name: AUO C070VW02 V2 7 inch 800×480 LCD Panel For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: C070VW02 V2
Price: 47 USD
Availability: InStock

SKU: C070VW02 V2

Model P/N: C070VW02 V2
Diagonal Size: 7"
Panel Type: a-Si TFT-LCD, LCM
Resolution: 800(RGB)×480, WVGA 133PPI
Pixel Format: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$50.00~~ $47.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

AUO C070VW02 V2 7 inch 800×480 LCD Panel For Industrial

Item	Specifications
Panel Model	C070VW02 V2
Manufacturer	AUO
Diagonal Size	7.0 inch
Resolution	800(RGB) × 480 (WVGA)
Display Mode	TN, Normally White, Transmissive
Active Area	152.40 × 91.44 mm
Outline Dimensions	165.0 × 104.0 × 10.75 mm
Brightness	320 cd/m² (Typ.)
Contrast Ratio	240:1 (Typ.)
Color Depth	262K colors (6-bit)
Response Time	6/10 ms (Tr/Td) (Typ.)
Viewing Angle	60/60/40/60 (L/R/U/D) (Typ.)
Surface Treatment	Anti-glare (Haze 5%)
Backlight	WLED, No driver included
Signal Interface	Parallel RGB (6-bit), 50 pins
Operating Temperature	-30°C ~ +85°C
Storage Temperature	-40°C ~ +85°C
