CA240128A/TG240128A-33 Compatible LCD Panel Screen Display For Industrial

Name: CA240128A/TG240128A-33 Compatible LCD Panel Screen Display For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: CA240128A/TG240128A-33
Price: 78 USD
Availability: InStock

SKU: CA240128A/TG240128A-33

Model: CA240128A / TG240128A‑33
Resolution: 240 × 128 dots
Display Mode: STN/FSTN, Positive, Transflective

0.0 (0 Reviews)

0 Sold

~~$80.00~~ $78.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

CA240128A/TG240128A-33 Compatible LCD Panel Screen Display For Industrial

Parameter	Specification
Model	CA240128A / TG240128A‑33
Resolution	240 × 128 dots (graphic)
Display Mode	STN/FSTN, Positive, Transflective
Background / Font	Yellow‑Green / Black; Blue / White optional
Controller	T6963C (compatible: RA6963)
Interface	8‑bit parallel (8080‑type)
Supply Voltage	3.3V DC (‑33 = 3.3V version)
Backlight	White/Yellow‑Green LED
Module Dimensions	144.0 × 104.0 × 13.0 mm
Viewing Area	114.0 × 64.0 mm
Dot Pitch	0.40 × 0.40 mm
Operating Temp	−20 °C to +70 °C
Storage Temp	−30 °C to +80 °C
RoHS	Compliant
