COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen

SKU: COM35H3R07ULC
Model P/N: COM35H3R07ULC
Diagonal Size: 3.5"
Panel Type: a-Si TFT-LCD, LCM
Pixel Number: 640(RGB)×960, 2:3, DVGA
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$50.00 $48.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
1/1
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
  • Description
COM35H3R07ULC Ortustech 3.5 inch 640×960 Industrial LCD Display Screen
Item Specification
Model COM35H3R07ULC
Size 3.5 inch
Display Type TFT LCD
Resolution 320(RGB)×480
Aspect Ratio 3:4
Interface MCU / SPI
Touch Panel Optional Capacitive Touch
Operating Temp -20℃ ~ +70℃
Storage Temp -30℃ ~ +80℃

Key Features

  • High brightness & wide viewing angle
  • Compact industrial-grade 3.5" design
  • Low power consumption for portable device
  • Support industrial high & low temperature environment
  • Widely used in medical equipment, industrial control, handheld terminal

Application

  • Industrial control display
  • Medical portable device
  • Smart home control panel
  • Handheld measurement instrument
