COM43H4M64ULC Ortustech 4.3 inch 480×800 LCD Panel Screen For Industrial

Name: COM43H4M64ULC Ortustech 4.3 inch 480×800 LCD Panel Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: COM43H4M64ULC
Price: 78 USD
Availability: InStock

SKU: COM43H4M64ULC

Model No.: COM43H4M64ULC
Screen Size: 4.3 inch
Screen Type: a-Si TFT-LCD, LCM
Number of dots: 480(RGB)×800, WVGA, 3:5
Dot Layout: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$80.00~~ $78.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

COM43H4M64ULC Ortustech 4.3 inch 480×800 LCD Panel Screen For Industrial

Parameter	Specification
Manufacturer	Ortustech
Model No.	COM43H4M64ULC
Screen Size	4.3 inch (diagonal)
Display Type	a-Si TFT-LCD, LCM
Resolution	480(RGB) × 800 (WVGA)
Dot Layout	RGB Vertical Stripe
Active Area	55.8 × 93 mm (H×V)
Outline Area	61.2 × 103 × 2.95 mm (H×V×D)
Weight	25.2 g (Typ.)
Surface Feature	Hard coating (2H)
Luminance	340 cd/m² (Typ.)
Contrast Ratio	600:1 (Typ., TM) / 5:1 (Typ., RF)
Viewing Angle	80/80/80/80 (Typ., CR≥10)
Response Time	40/60 ms (Max., Tr/Td)
Refresh Rate	60 Hz
Display Colors	16.7M (24-bit true color)
Backlight	7S1P WLED, 20,000 hrs, No Driver
Signal Type	MIPI (2 data lanes), 25-pin FPC
Voltage Supply	3.3/1.8 V (Typ., VDD/VCCIO)
Touchscreen	Without touch panel
Operating Temperature	-20 ~ +70 °C
Storage Temperature	-30 ~ +80 °C
Compliance	RoHS Certified
