Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial

SKU: COM50H5N17ULC
Model P/N: COM50H5N17ULC
Diagonal Size: 5"
Panel Type: a-Si TFT-LCD, LCM
Pixel Number: 720(RGB)×1280, WXGA, 9:16
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$100.00 $98.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
1/1
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
  • Description
Ortustech 5 Inch 720×1280 COM50H5N17ULC LCD Panel Screen For Industrial
Parameter Details
Diagonal Size 5.0 inches (126.0 mm)
Resolution 720 (RGB) × 1280 pixels (Portrait)
Display Mode Transflective (Blanview-2), Normally WhiteTOPPAN Inc.
Active Area 61.776 (H) × 109.824 (V) mm
Outline Dimensions 67.84(W)×120.22(H)×2.4(D) mm
Pixel Pitch 0.0286 (H) × 0.0858 (V) mm
Weight 34 g
Interface MIPI DSI (4-lane), 27-pin ZIF connectorTOPPAN Inc.
Viewing Angle 80/80/80/80 (Min.)(CR≥10)
Brightness 400 cd/m² (Typ.)
Contrast Ratio 800:1 (Typ.)
Color Depth 16.7M (8-bit)
Response Time 100 ms (Typ.)
Operating Temperature -20°C to +70°CTOPPAN Inc.
Storage Temperature -30°C to +80°CTOPPAN Inc.
Surface Hardness 2H (Polarizer)

Features

  • Blanview-2 Technology: 2nd generation transflective display for excellent sunlight readability and low power consumption.
  • Ultra-thin: Only 2.15 mm thick.
  • Wide Temperature: Suitable for harsh industrial and outdoor environments.
  • High Definition: 720×1280 HD resolution for sharp image quality.
  • Low Power Consumption: Optimized for battery-powered devices.

Applications

  • Handheld Industrial Devices: Rugged PDAs, barcode scanners, and portable data terminals.
  • Outdoor Equipment: GPS navigation, marine displays, and industrial control panels.
  • Medical Devices: Portable patient monitors and diagnostic equipment.
  • Automotive: In-vehicle displays and dashcams.
  • Consumer Electronics: High-end smartwatches, action cameras, and outdoor cameras.
  • Military & Aerospace: Portable battlefield displays and avionics (non-military certified).
