Innolux DJ101IA-07A 10.1 inch 1280x720 WXGA TFT LCD Display for Industrial

Name: Innolux DJ101IA-07A 10.1 inch 1280x720 WXGA TFT LCD Display for Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: DJ101IA-07A
Price: 80 USD
Availability: InStock

SKU: DJ101IA-07A

Model: DJ101IA-07A
Diagonal Size: 10.1 inch
Type: a-Si TFT-LCD, LCM
Resolution: 1280(RGB)×720 (WXGA, 16:9)
Pixel Format: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$88.00~~ $80.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Innolux DJ101IA-07A 10.1 inch 1280x720 WXGA TFT LCD Display for Industrial

Parameter	Details
Brand	Innolux
Model	DJ101IA-07A
Diagonal Size	10.1 inch
Type	a-Si TFT-LCD, LCM
Resolution	1280(RGB)×720 (WXGA, 16:9)
Pixel Format	RGB Vertical Stripe
Active Area	223.68(H) × 125.82(V) mm / 8.81" × 4.95"
Outline Size	238.6(H) × 148(V) × 9.7(D) mm / 9.39" × 5.83" × 0.38"
Weight	330g (Max.) / 0.73 lb
Luminance	750 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
Response Time	10/15 ms (Typ.) (Tr/Td)
View Direction	Symmetry
Viewing Angle	85°/85°/85°/85° (Typ., CR≥10)
Display Mode	AAS, Normally Black, Transmissive
Display Colors	262K / 16.7M, 70% NTSC
Backlight	WLED, 20,000 hrs lifespan, Without Driver
Refresh Rate	60Hz
Touch Panel	Without Touchscreen
Interface	LVDS (1 ch, 6/8-bit), 40-pin Connector
Power Supply	3.3V (Typ.)
Operating Temperature	-30 ~ +85 °C
Storage Temperature	-40 ~ +90 °C
Surface Feature	Anti-Glare

Applications

Automotive Displays: In-vehicle infotainment systems, rear-seat entertainment, and driver information panels.
Industrial Control Panels: Outdoor HMI, factory automation, and rugged industrial control terminals.
Marine & Outdoor Equipment: Marine navigation displays, outdoor monitoring terminals, and rugged portable devices.
Kiosks & POS Systems: Outdoor self-service kiosks, digital signage, and industrial POS terminals.
