DMF-50840NB-FW | Kyocera Optrex 5.7" QVGA Blue STN Monochrome LCD Graphic Module
DMF-50840NB-FW is a classic 5.7-inch 320×240 QVGA monochrome blue STN graphic LCD module originally manufactured by Optrex (now Kyocera Display). It adopts transmissive blue-mode STN technology, single CCFL backlight, onboard LCD controller, 4-bit parallel 14-pin interface, metal frame industrial structure, and standard 0~50°C operating temperature. This robust monochrome display is widely used for legacy injection molding machine HMI, laboratory analytical instruments, mining control equipment, medical diagnostic devices, and drop-in replacement screens for discontinued industrial equipment.
| Parameter Item |
Specification Details |
| Full Part Number |
DMF-50840NB-FW (suffix variants: BEN / ASE-BFN) |
| Manufacturer |
Optrex (Kyocera Display) |
| Diagonal Size |
5.7 inch, landscape, 4:3 |
| Native Resolution |
320(H) × 240(V) dots (QVGA monochrome graphic) |
| LCD Technology |
FSTN / STN, Blue background, white font, Transmissive |
| Dot Size |
0.33 mm (W) × 0.33 mm (H) |
| Dot Pitch |
0.36 mm (W) × 0.36 mm (H) |
| Active View Area (AA) |
120.0 mm (W) × 90.0 mm (H) |
| Overall Outline Dimension |
167.1(W) × 109.0(H) × 11.0(D) mm (exclude connectors) |
| Typical Brightness |
60 cd/m² |
| Typical Contrast Ratio |
5:1 |
| Viewing Angle (Reference Direction: 6 o'clock) |
Horizontal ±45°, Vertical -40°/+25° |
| Response Time (Tr / Td) |
270 ms / 400 ms (Typical) |
| Backlight System |
Single CCFL lamp, service life ≥25,000 hours, without built-in inverter |
| Signal Interface |
4-bit parallel MCU bus, 14-pin FPC flat cable connector |
| Built-in Controller |
Integrated graphic LCD driver IC, support text & curve display |
| Logic Supply Voltage (VCC) |
4.5 VDC ~ 5.5 VDC (Typ. 5V) |
| LCD Drive Voltage |
19.9 ~ 24.9 V adjustable |
| Refresh Mode |
1/240 duty cycle, 1/14 bias |
| Operating Temperature |
0°C ~ +50°C |
| Storage & Transport Temp |
-20°C ~ +60°C |
| Touch Function |
No integrated touch panel |
| Housing Structure |
Metal shielding frame, anti-electromagnetic interference |
| Net Weight |
Max 230 g |
| Compliance |
RoHS lead-free compliant |
| Production Status |
Discontinued original production, mass stock only for equipment maintenance replacement |
