DOP-B07S411 | Delta 7" WVGA Resistive Touch HMI
DOP-B07S411 is a 7-inch widescreen industrial HMI by Delta Electronics, featuring a 4-wire resistive touchscreen, 800×480 WVGA TFT LCD with 65,536 colors, and LED backlight. Designed for panel mounting, it offers IP65 front protection, multiple serial ports, and USB host/device interfaces, ideal for factory automation, machinery control, and process monitoring in harsh industrial environments.
| Parameter Item |
Specification Details |
| Part Number |
DOP-B07S411 |
| Manufacturer |
Delta Electronics |
| Display Size |
7-inch widescreen, 16:9 aspect ratio |
| Resolution |
800 × 480 pixels (WVGA) |
| Display Type |
TFT LCD, 65,536 colors |
| Touch Technology |
4-wire analog resistive touchscreen |
| Active Area |
154.08 mm (W) × 85.92 mm (H) |
| Brightness |
400 cd/m² (typical) |
| Backlight |
LED, lifespan ≥20,000 hours (25°C) |
| System Memory |
Flash ROM: 128 MB; RAM: 64 MB |
| Communication Ports |
COM1: RS-232; COM2: RS-232/RS-485; COM3: RS-422/RS-485 |
| USB |
1× USB Host (Ver 1.1); 1× USB Device (Ver 2.0) |
| Power Supply |
DC 24V (–10% ~ +15%), 4W typical |
| Operating Temperature |
0°C ~ +50°C |
| Storage Temperature |
–20°C ~ +60°C |
| Front Protection |
IP65 / UL Type 4X (dust & water resistant) |
| Mounting |
Panel mount |
| Dimensions (W×H×D) |
215 × 161 × 50 mm |
| Weight |
Approx. 0.82 kg |
| Certification |
CE, UL, RoHS |
