EDT ET057002DH6 5.7" TFT-LCD Display 320×240 WLED Backlight Industrial Panel

Name: EDT ET057002DH6 5.7" TFT-LCD Display 320×240 WLED Backlight Industrial Panel
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: ET057002DH6
Price: 120 USD
Availability: InStock

SKU: ET057002DH6

Model: ET057002DH6
Size: 5.7 inches
Panel Type: a-Si TFT-LCD
Resolution: 320 × 240 (QVGA)

0.0 (0 Reviews)

0 Sold

~~$122.00~~ $120.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

EDT ET057002DH6 5.7" TFT-LCD Display 320×240 WLED Backlight Industrial Panel

Parameter	Details
Model	ET057002DH6
Brand	EDT
Size	5.7 inches
Panel Type	a-Si TFT-LCD
Resolution	320 × 240 (QVGA)
Brightness	380 cd/m² (Typ.)
Contrast Ratio	300:1 (Typ.)
Viewing Angle	67/67/62/67 (Typ., CR≥10)
Display Colors	262k/16.7m, 54% CIE1931
Display Area	115.2 × 86.4 mm
Outline Size	124.7 × 100 mm
Backlight	WLED, 9s2p, 40,000 hours (no driver)
Interface	Parallel RGB (1 ch 6/8-bit), 50 pins FPC
Operating Temperature	-10°C ~ 60°C
Storage Temperature	-20°C ~ 70°C
Touch Screen	Equipped
Display Mode	TN, Normally White, Transmissive

Applications

Industrial PCs & HMI: Human-machine interfaces for manufacturing machinery, production lines, and industrial control systems.
Factory Automation: PLC control panels, CNC machine tools, and robotic operation terminals.
Medical Equipment: Patient monitors, diagnostic devices, and medical instrumentation requiring reliable displays.
Marine & Transportation: On-board displays for vessels, trains, and heavy-duty vehicles (wide temperature tolerance).
Outdoor Kiosks: Information terminals, ticket machines, and outdoor monitoring screens (high brightness & durability).
