ETML0700E9DH6 7 inch LCD Panel Screen For Industrial

Name: ETML0700E9DH6 7 inch LCD Panel Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: ETML0700E9DH6
Price: 108 USD
Availability: InStock

SKU: ETML0700E9DH6

Model: ETML0700E9DH6
Size: 7.0 inch, WVGA 800×480 (15:9)
Display Type: a-Si TFT-LCD, transmissive

0.0 (0 Reviews)

0 Sold

~~$110.00~~ $108.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

ETML0700E9DH6 7 inch LCD Panel Screen For Industrial

Specification	Details
Model	ETML0700E9DH6 (EDT)
Size	7.0 inch, WVGA 800×480 (15:9)
Display Type	a-Si TFT-LCD, transmissive, LED backlight
Brightness	290 cd/m² (typical)
Colors	16.7M (24-bit RGB)
Interface	RGB (TTL)
Touch Panel	Without touch function
Active Area	152.4 × 91.44 mm (H×V)
Outline Size	166 × 105.44 × 8.16 mm (W×H×D)
Operating Temp	-20°C ~ +70°C
Storage Temp	-30°C ~ +80°C
Features	Industrial grade, anti-glare surface, RoHS compliant

Typical Applications

Industrial HMI & Control Panels: Factory automation, PLC operator interfaces, CNC machinery
Smart Home & Building Automation: Central control panels, thermostat/security displays
Medical Portable Devices: Diagnostic equipment, patient monitors, handheld clinical instruments
Retail & Kiosk Systems: POS terminals, self-service kiosks, vending machine displays
Transportation & Logistics: Vehicle-mounted terminals, delivery truck dashboards, cargo tracking screens
