EW10251YLY Compatible LCD Panel Screen For Industrial

Name: EW10251YLY Compatible LCD Panel Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: EW10251YLY
Price: 78 USD
Availability: InStock

SKU: EW10251YLY

Model Number : EW10251YLY (Part No. 20-20023-2 REV.D)
Display Format : 2 rows × 40 characters (2x40)
Display Type : STN-LCD (Super Twisted Nematic)

0.0 (0 Reviews)

0 Sold

~~$80.00~~ $78.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

EW10251YLY Compatible LCD Panel Screen For Industrial

Parameter	Details
Model Number	EW10251YLY (Part No. 20-20023-2 REV.D)
Display Format	2 rows × 40 characters (2x40)
Display Type	STN-LCD (Super Twisted Nematic)
Display Mode	Transflective, Normally White
Character Font	5×7 dot matrix
Viewing Direction	6 o'clock (Bottom View)
Backlight Type	LED Backlight (Yellow-Green / White-Green optional)
Operating Temperature	-20°C ~ +70°C (Industrial Grade)
Storage Temperature	-30°C ~ +80°C
Supply Voltage	5V DC (Typical)
Interface	Parallel 8-bit / 4-bit MPU Interface
Outline Dimensions	146.0 (W) × 38.0 (H) × 12.0 (D) mm (Typical)
Active Area	122.0 (W) × 24.0 (H) mm (Typical)
Certification	RoHS Compliant
Application	Replacement for Mitsubishi LE-40MTA-E Tension Controller

Key Features

Industrial-Grade Reliability: Wide temperature range for 24/7 operation in factory automation environments.
2x40 Character Format: Matches the display requirement of Mitsubishi LE-40MTA-E tension controller.
STN Transflective Technology: Good readability in both indoor and outdoor lighting conditions.
Long-Life LED Backlight: Low power consumption and extended service life compared to CCFL.
Standard Parallel Interface: Easy integration with industrial control systems.
RoHS Compliance: Meets global environmental standards for lead-free manufacturing.
