EDT EW50702FLY 5.7 Inch LCD Screen Display Panel for Industrial

Name: EDT EW50702FLY 5.7 Inch LCD Screen Display Panel for Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: EW50702FLY
Price: 52 USD
Availability: InStock

SKU: EW50702FLY

Model No.: EW50702FLY
Diagonal Size: 5.7 inches
Resolution: 128 × 64 dots (Monochrome)
Panel Type: FSTN-LCD, Monochrome, Transmissive

0.0 (0 Reviews)

0 Sold

~~$54.00~~ $52.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

EDT EW50702FLY 5.7 Inch LCD Screen Display Panel for Industrial

Parameter	Specification
Manufacturer	EDT (Everdisplay Optronics)
Model No.	EW50702FLY
Supplier Part No.	20-20620-3
Diagonal Size	5.7 inches
Resolution	128 × 64 dots (Monochrome)
Panel Type	FSTN-LCD, Monochrome, Transmissive
Display Mode	Positive / Negative (FSTN)
Backlight	White LED (WLED)
Interface	26-pin Header (CL, DATA, EN, RS, R/W, VCC, GND, etc.)
Brightness	~5 cd/m² (Typical)
Contrast Ratio	15:1 (Typical)
Operating Temperature	-20°C ~ +70°C
Storage Temperature	-30°C ~ +80°C
Outline Dimensions	145.0 × 102.0 × 12.5 mm (Reference)
Active Area	115.2 × 86.4 mm (Reference)
Pixel Pitch	0.36 × 0.36 mm (Reference)
Weight	~200 g (Reference)

Typical Applications

Industrial Control & Automation: PLC controllers, HMIs, factory automation terminals, and motion control systems.
Test & Measurement Equipment: Data loggers, precision meters, oscilloscopes, and spectrum analyzers.
Medical Devices: Portable patient monitors, diagnostic instruments, and medical analysis tools.
Marine & Offshore Systems: Shipboard control panels, navigation displays, and marine monitoring units.
Telecommunication Infrastructure: Base station controllers, network monitoring devices, and communication hubs.
Agricultural Machinery: Tractor instrument panels, farm equipment controllers, and irrigation system displays.
Retail & POS Terminals: Industrial-grade point-of-sale systems and self-service kiosks.
