The EW50722NCW is a 7.2-inch monochrome FSTN-LCD module designed for industrial applications requiring reliable character and simple graphic display performance. With a VGA resolution of 640×480 pixels (4:3 aspect ratio), it delivers clear black-and-white negative images in transmissive mode.
| Parameter |
Value |
| Model Name |
EW50722NCW |
| Display Size |
7.2" |
| Panel Type |
FFFSTN-LCD, LCM |
| Resolution |
640×480, VGA, 4:3 |
| Dot Layout |
Rectangle |
| Display Area |
147.18(W)×110.38(H) mm |
| Outline Size |
205.5(W)×141(H)×7(D) mm |
| Brightness |
80 cd/m² (Typ.) |
| Contrast Ratio |
20:1 (Typ.) (TM) |
| Viewing Angle |
30/30/25/25 (Typ.)(CR≥10) |
| Display Mode |
STN, Black/White (Negative), Transmissive |
| View Direction |
6 o'clock |
| Response Time |
300/140 (Typ.)(Tr/Td) ms |
| Display Colors |
Monochrome |
| Touch Screen |
Without |
| Light Source |
1 pcs CCFL, 50K hrs, Without Driver |
| Frequency |
85Hz |
| Interface |
Parallel Data (2ch, 4-bit), 15 pins FPC |
| Input Voltage |
3.3/5.0V (Typ.)(VDD) |
| Operating Temp. |
0 ~ 50 °C |
| Storage Temp. |
-20 ~ 70 °C |
☛Delivery Details:
We will arrange the shipment within 1-3 working days asap after got your payment. And the tracking number and commercial inovice will be given to the customers asap. (only the standard speedpak or expedited shipping service). Expedited Shipping by DHL/FEDEX/4PX express Courier etc. But sometimes it is highly depended on buyer's payment, the courier company and local customs/duties.
