The Data Image FG050700DSSWDG10 is a 5.7-inch industrial-grade a-Si TFT-LCD module featuring an integrated 4-wire resistive touch screen. Designed for reliable performance in demanding environments, this QVGA display combines clear optical performance with robust mechanical construction, making it an excellent choice for human-machine interfaces (HMI), industrial control systems, medical devices, and commercial equipment.
| Parameter |
Specification |
| Mfr. |
Data Image |
| Model Name |
FG050700DSSWDG10 |
| Display Size |
5.7" |
| Panel Type |
a-Si TFT-LCD, LCM |
| Resolution |
320(RGB)×240, QVGA, 4:3 |
| Pixel Format |
RGB Vertical Stripe |
| Display Area |
115.2(W)×86.4(H) mm |
| Panel Weight |
242g (Typ.) |
| Outline Size |
144(W)×104.6(H)×15.6(D) mm |
| Surface |
Antiglare |
| Brightness |
320 cd/m² (Typ.) |
| Contrast Ratio |
320:1 (Typ.) (TM) |
| Viewing Angle |
70/70/70/50 (Typ.)(CR≥10) |
| Display Mode |
TN, Normally White, Transmissive |
| View Direction |
12 o'clock |
| Response Time |
15/35 (Typ.)(Tr/Td) ms |
| Display Colors |
262K |
| Frequency |
60Hz |
| Touch Screen |
4-wire Resistive Touch |
| Light Source |
3S7P WLED, 40K hrs, Without Driver |
| Interface |
Parallel RGB (1 ch, 6-bit), 33 pins Connector |
| Input Voltage |
3.3V (Typ.) |
| Operating Temperature |
-20 ~ 70 °C |
| Storage Temperature |
-30 ~ 80 °C |
