The Data Image FG0700K5DSSWBG01 is a 7.0-inch a-Si TFT-LCD module engineered by Data Image for demanding industrial and automotive applications . This model combines reliable performance, high brightness, and an integrated LED driver, making it a versatile solution for various professional environments .
| Brand |
Data Image |
| Model P/N |
FG0700K5DSSWBG01 |
| Diagonal Size |
7.0" |
| Panel Type |
a-Si TFT-LCD, LCM |
| Resolution |
800(RGB)×480, WVGA 133PPI |
| Pixel Format |
RGB Vertical Stripe |
| Active Area |
152.4(W)×91.44(H) mm |
| Bezel Opening |
155.3(W)×94.3(H) mm |
| Outline Size |
165(W)×104.44(H)×9.7(D) mm |
| Surface |
Antiglare |
| Brightness |
500 cd/m² (Typ.) |
| Contrast Ratio |
400:1 (Typ.) (TM) |
| Viewing Angle |
70/70/60/60 (Typ.)(CR≥10) |
| Display Mode |
TN, Normally White, Transmissive |
| Best View on |
6 o'clock |
| Response Time |
5/11 (Typ.)(Tr/Td) |
| Display Colors |
262K 45% NTSC |
| Lamp Type |
3S8P WLED , 20K hours , With LED Driver |
| Frequency |
60Hz |
| Touch Screen |
Without |
| Weight |
128g (Typ.) |
| Signal Interface |
Parallel RGB (1 ch, 6-bit) , 40 pins FPC |
| Input Voltage |
3.3V (Typ.) |
| Environment |
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
