| Parameter Name | Technical Specifications |
|---|---|
| Panel Brand | AUO (AU Optronics) |
| Model Number | G057VN01 V2 |
| Diagonal Size | 5.7 inches (145mm) |
| Resolution | 640×480 (VGA), 141 PPI |
| Pixel Arrangement | RGB Vertical Stripes |
| Active Area (W×H) | 115.2 × 86.4 mm |
| Outline Dimensions | 144(W) × 104.6(H) × 12.8(D) mm |
| Brightness | 700 cd/m² (Typical) |
| Contrast Ratio | 800:1 (Typical) |
| Viewing Angle | Left 80° / Right 80° / Up 70° / Down 70° (CR≥10) |
| Optical Mode | TN Normally White, Transmissive |
| Response Time | Rising 15ms / Falling 10ms |
| Refresh Frequency | 60Hz |
| Surface Treatment | Anti-glare, Hard coating (3H) |
| Backlight System | WLED with driver, Lifespan ≥ 50,000 hours |
| Signal Interface | CMOS (1ch, 6-bit), 33-Pin Terminal |
| Power Supply Voltage | 3.3V (Typical) |
| Operating Temperature | -30°C to +85°C |
| Storage Temperature | -30°C to +85°C |
| Weight | Approx. 150g |
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
