AUO G070VAN01.0 7 Inch LCD Display Screen For Industrial

Name: AUO G070VAN01.0 7 Inch LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: G070VAN01.0
Price: 86 USD
Availability: InStock

SKU: G070VAN01.0

Model P/N: G070VAN01.0
Diagonal Size: 7"
Panel Type: a-Si TFT-LCD, LCM
Resolution: 800×480(RGB), WVGA 133PPI
Pixel Format: RGB Horizontal Stripe

0.0 (0 Reviews)

0 Sold

~~$88.00~~ $86.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

AUO G070VAN01.0 7 Inch LCD Display Screen For Industrial

Parameter	Specification
Brand & Model	AUO G070VAN01.0
Diagonal Size	7.0 inches
Resolution	800 × 480 (RGB) WVGA
Display Mode	AHVA (Advanced Hyper View Angle), Normally Black, Transmissive
Active Area	152.4 (H) × 91.44 (V) mm
Pixel Pitch	0.1905 × 0.1905 mm (133 PPI)
Brightness (Typ.)	480 cd/m²
Contrast Ratio (Typ.)	1300:1
Viewing Angle	89°/89°/89°/89° (CR≥10)
Response Time	11/19 ms (Tr/Td, Max.)
Color Depth	6/8-bit, 262K / 16.7M colors; 70% NTSC
Refresh Rate	60 Hz
Interface	LVDS (1 channel, 6/8-bit), 30-pin connector
Logic Voltage	3.3 V (Typ., 3.0–3.6 V)
Panel Current	140 mA (Typ.), 200 mA (Max.)
Backlight	WLED (7S2P), side-lit; Lifetime: 70,000 hrs (Typ.)
Backlight Driver	Not integrated (external driver required)
Backlight Current	92 mA (Typ.)
Outline Dimensions	166.6 (W) × 107.0 (H) × 10.0 (D) mm
Surface Treatment	Anti-glare (Matte), Hard Coating (3H)
Operating Temp.	-20°C to +70°C
Storage Temp.	-30°C to +80°C
Production Status	In mass production
RoHS	Compliant
