G10401
G10401 is a 10.4-inch 8-wire resistive touch panel manufactured by Gunze, designed for industrial environments. It features high durability, anti-glare surface, ≥79% light transmittance, and wide temperature tolerance, supporting reliable input with gloves or stylus in harsh conditions.
| Parameter |
Details |
| Model |
G10401 |
| Brand |
Gunze |
| Technology |
8-wire resistive touch |
| Diagonal Size |
10.4 inches |
| Aspect Ratio |
4:3 |
| Outline Dimensions (W×H) |
227.3 × 175.6 mm |
| Active Area (W×H) |
211.2 × 158.4 mm |
| Thickness |
1.8 mm (glass) |
| Surface Treatment |
Hard coating (3H hardness), anti-glare (8% haze) |
| Transmittance |
≥79% (typical 80%, ASTM D1003) |
| Resolution |
4096 × 4096 points |
| Operating Force |
20–80 g |
| Lifespan |
≥1 million touches |
| Interface |
FPC (8-pin, 1.0 mm pitch) |
| Cable Length |
81 mm (9 o’clock exit) |
| Operating Temperature |
−10°C ~ +60°C |
| Storage Temperature |
−20°C ~ +70°C |
| Humidity |
0%–90% RH (operating, non-condensing) |
| Certifications |
RoHS compliant |
| Weight |
Approx. 100 g
|
