| Basic Info |
Manufacturer |
Innolux (CHIMEI) |
- |
- |
|
Model |
G121AGE-L03 Rev.C1 |
- |
- |
|
Panel Type |
a‑Si TFT‑LCD Module (LCM) |
- |
MVA mode |
|
Diagonal Size |
12.1 |
inch |
- |
|
Resolution |
800 × 600 |
pixel |
SVGA |
|
Pixel Format |
RGB Vertical Stripe |
- |
- |
|
Display Mode |
Normally Black, Transmissive |
- |
- |
|
Surface Treatment |
Hard Coating (3H), Anti‑Glare (Haze 25%) |
- |
- |
|
Production Status |
Mass Production |
- |
- |
|
RoHS |
Compliant |
- |
- |
| Optical |
Brightness (Typ.) |
450 |
cd/m² |
- |
|
Contrast Ratio (Typ.) |
1500:1 |
- |
- |
|
Viewing Angle (Typ., CR≥10) |
89°/89°/89°/89° |
° |
L/R/U/D |
|
Response Time (Typ., GtG) |
13/12 (Typ.)(Tr/Td) |
ms |
Tr/Td: 13/12 ms |
|
Color Depth |
262K / 16.2M |
colors |
6‑bit / 8‑bit selectable |
|
Backlight Type |
WLED (White LED) |
- |
Replaceable light bar |
|
Backlight Lifetime (Typ.) |
50,000 |
hours |
- |
|
Backlight Driver |
Built‑in |
- |
- |
| Mechanical |
Active Area (W×H) |
246.0 × 184.5 |
mm |
- |
|
Outline Dimension (W×H×D) |
260.5 × 204.0 × 8.4 |
mm |
Typ. |
|
Pixel Pitch |
0.3075 × 0.3075 |
mm |
- |
|
Net Weight |
506/530g (Typ./Max.) |
g |
Max. |
|
Mounting |
Standard Screw Holes |
- |
- |
| Electrical |
Signal Interface |
20‑pin 1‑ch LVDS |
- |
- |
|
Input Voltage |
DC 3.3 |
V |
- |
|
Operating Voltage |
DC 3.0–3.6 |
V |
- |
|
Power Consumption (Typ.) |
7.9 |
W |
- |
|
Scan Direction |
Reversible |
- |
- |
|
Signal Mode |
DE (Data Enable) Only |
- |
- |
| Environmental |
Operating Temperature |
-30 to +85 |
°C |
- |
|
Storage Temperature |
-30 to +85 |
°C |
- |
|
Humidity |
5%–95% RH |
- |
Non‑condensing |
|
Vibration Resistance |
1.5G |
- |
14.7 m/s² |
| Applications |
Core Scenarios |
Industrial HMI, Factory Automation, Medical Monitors, Marine/Transport Displays, Test & Measurement, Amusement Equipment, Rugged Embedded Systems |
- |
- |
