| Part Number |
G150XNE-L03 |
| Manufacturer |
Innolux |
| Display Type |
a-Si TFT-LCD Module |
| Display Mode |
NPVA, Normally Black, Transmissive |
| Diagonal Size |
15.0 inches |
| Resolution |
1024(RGB) × 768 (XGA, 85 PPI) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Dot Pitch |
0.297 × 0.297 mm (W×H) |
| Active Area |
304.13(W) × 228.10(H) mm |
| Outline Dimension |
326.5(W) × 253.5(H) × 9.1±0.5(D) mm |
| Surface Treatment |
Anti-glare (Matte), Hard Coating (3H) |
| Weight |
0.96 kg (Typ.), 1.00 kg (Max.) |
| Brightness |
300 cd/m² (Typ.) |
| Contrast Ratio |
2000:1 (Typ.) |
| Response Time |
16/7 ms (Tr/Td, Typ.) |
| Viewing Angle |
88°(L/R/U/D) |
| Display Colors |
262K (6-bit) / 16.2M (6-bit + FRC) |
| Backlight |
White LED (WLED), Built-in Driver |
| Backlight Lifetime |
≥70,000 hours (Min.) |
| Backlight Power |
3.5 W (Typ.), 4.2 W (Max.) |
| Interface |
LVDS (1 channel, 6/8-bit, 20-pin) |
| Supply Voltage |
VCC: 3.0–3.6 V (Typ. 3.3 V) |
| Operating Temperature |
-20°C to +70°C |
| Storage Temperature |
-30°C to +70°C |
| Vibration Resistance |
1.5G (14.7 m/s²) |
| RoHS Compliance |
Yes |
| Production Status |
In Mass Production |
