G154EVN01.0 15.4inch industrial Lcd Display Panel for AUO

Name: G154EVN01.0 15.4inch industrial Lcd Display Panel for AUO
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: G154EVN01.0
Price: 192 USD
Availability: InStock

SKU: G154EVN01.0

1，Condition: New，Grade A

2，Description: G154EVN01.0 15.4inch LCD Display Panel

3，Warranty: 90 Days

4，Lead Time: 1-3 Working days

5，Shipping: DHL ,FedEx, EMS , SF express or by air.

6，Packaging: Bubble pad+Paper box

7，Note: All LCD display panels will be full tested before shipping.

0.0 (0 Reviews)

0 Sold

~~$200.00~~ $192.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

The AUO G154EVN01.0 is a 15.4-inch industrial-grade TFT-LCD module designed for demanding applications that require high image quality, excellent readability, and robust performance . Developed by AU Optronics (AUO), this model utilizes advanced AMVA3 (Advanced MVA) technology to deliver superior optical characteristics .

Parameter	Specification
Brand	AUO
Model	G154EVN01.0
Diagonal Size	15.4 inch
Type	a-Si TFT-LCD, LCM
Pixel Number	1280(RGB)×800, WXGA, 16:10
Pixel Format	RGB Vertical Stripe
Active Area	331.2(H) × 207(V) mm
Physical Size	352(H) × 230(V) × 9.05(D) mm
Mass	900g (Typ.)
Surface Coating	Antiglare, Hard coating (3H)
Luminance	400 cd/m² (Typ.)
Contrast Ratio	3000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	30 (Typ.)(Tr+Td) ms
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Operating Mode	AMVA3, Normally Black, Transmissive
Support Color	16.7M, 45% NTSC
Light Source	WLED, 50K hrs, With LED Driver
Frame Rate	60Hz
Touch Panel	Without
Interface Type	LVDS (1 ch, 8-bit), 30 pins Connector
Power Supply	3.3V (Typ.)
Operating Temperature	–10 ~ 70 °C
Storage Temperature	–20 ~ 80 °C

Simple Applications

Application Area	Use Case Description
Industrial HMI	Control panels and operator interfaces for CNC machines, assembly lines, and factory automation systems
Medical Imaging	Diagnostic displays, patient monitors, and medical cart terminals requiring high contrast and accurate grayscale reproduction
Test & Measurement	Oscilloscopes, signal analyzers, and data acquisition systems with detailed waveform and chart display
Commercial Display	Digital signage, kiosk terminals, and information display systems in retail or public spaces
Transportation & Logistics	Warehouse management terminals, portable inspection devices, and vehicle-mounted systems with mild vibration exposure
Military/Aerospace	Ruggedized display solutions in non-critical ground support equip
