AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial

SKU: G156HAB01.0
Model P/N: G156HAB01.0
Diagonal Size: 15.6"
Panel Type: a-Si TFT-LCD, Assembly
Pixel Number: 1920(RGB)×1080, 16:9, FHD
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$102.00 $100.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
1/1
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
  • Description
AUO G156HAB01.0 15.6 inch 1920×1080 LCD Display Screen For Industrial
Parameter Value Unit
Model G156HAB01.0 -
Brand AUO (AU Optronics) -
Panel Type a-Si TFT-LCD, LCM (Assembly) -
Diagonal Size 15.6 inch
Resolution 1920 (RGB) × 1080 (FHD) pixels
Pixel Arrangement RGB Vertical Stripe -
Active Area 344.16 × 193.59 mm
Outline Dimension 361 × 227 × 4.9 mm
Brightness (Typ.) 300 cd/m²
Contrast Ratio (Typ.) 800:1 -
Display Colors 16.2M (24-bit), 45% NTSC -
Viewing Angle (Typ.) 89/89/89/89 (L/R/U/D) degrees
Response Time (Typ.) 25 (Tr+Td) ms
Display Mode AHVA, Normally Black, Transmissive -
Backlight WLED (30,000 hrs), with LED Driver -
Interface eDP 1.2 (2 lanes, 40 pins) -
Touch On-Cell Touch (10-point PCAP) -
Input Voltage 3.3 V
Operating Temperature 0 ~ +50 °C
Storage Temperature -20 ~ +60 °C
Weight (Max.) 620 g
Surface Treatment Hard coating (7H) -
RoHS Compliance Yes -

Applications

  • Industrial HMI & Control Panels: Factory automation, PLC interfaces, industrial workstations.
  • Medical Equipment: Patient monitors, diagnostic devices, medical imaging systems.
  • Automotive Displays: In-vehicle infotainment, instrument clusters, rear-seat entertainment.
  • Retail & POS: Industrial POS terminals, digital signage, kiosks.
  • Embedded Systems: Industrial PCs, rugged tablets, IoT terminals.
