TFT Color LCD Touch Panel HMI
Manufacturer: Pro-face (now part of Schneider Electric)
Series: GP-577R Series
Product Type: TFT Color LCD Touch Panel HMI
| Attribute | Specification |
|---|---|
| Display Type | TFT True Color LCD -1 |
| Display Size | 12.1 inches -1 |
| Resolution | 800 × 600 pixels -1 |
| Display Colors | 256 colors (no flicker) / 64 colors (3-speed flicker) -1 |
| Backlight Type | CCFL (Cold Cathode Fluorescent Lamp) -1 |
| Backlight Lifespan | Over 50,000 hours (24-hour continuous operation) -1 |
| Brightness Control | 4 levels adjustable via touch panel -1 |
| Attribute | Specification |
|---|---|
| Rated Power Supply | DC24V -1 |
| Voltage Range | DC24V nominal |
| Attribute | Specification |
|---|---|
| Supported Fonts | ASCII, Japanese, Korean, Taiwanese, Chinese -7 |
| Character Sizes | Standard fonts: 8×8, 8×16, 16×16, 32×32 pixels |
| Font Scaling | Width: 1, 2, 4, 8 times; Height: 1, 2, 4, 8 times |
Note: Based on similar GP577R series models.
| Attribute | Specification |
|---|---|
| Front Panel Rating | Equivalent to IP65f (dust-tight, protected against water jets) -7 |
| Operating Temperature | 0°C to 40°C (or 0°C to 50°C per some sources) -7 |
| Storage Temperature | -20°C to 60°C |
| Operating Humidity | 30% to 85% RH (non-condensing) -7 |
| Cooling Method | Natural air circulation |
| Attribute | Specification |
|---|---|
| Agency Approvals | UL/c-UL Listed, CE Marking |
The GP577R series has several variants. Key differences include:
