HDM3224-1-9RXF compatible LCD Display Screen For Industrial

Name: HDM3224-1-9RXF compatible LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: HDM3224-1-9RXF
Price: 154 USD
Availability: InStock

SKU: HDM3224-1-9RXF

Model: HDM3224-1-9RXF
Display Type: FSTN-LCD, Monochrome
Diagonal Size: 5.7 inches
Resolution: 320 × 240 pixels

0.0 (0 Reviews)

0 Sold

~~$160.00~~ $154.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

HDM3224-1-9RXF compatible LCD Display Screen For Industrial

Parameter	Specification
Model	HDM3224-1-9RXF
Display Type	FSTN-LCD, Monochrome
Diagonal Size	5.7 inches
Resolution	320 × 240 pixels
Viewing Area	122.0 × 92.0 mm
Module Dimensions	167.0 × 109.0 × 11.0 mm
Backlight	CCFL (Cold Cathode Fluorescent Lamp)
Brightness	200–220 cd/m²
Contrast Ratio	40:1
Viewing Angle	45°/45°/30°/40° (L/R/U/D)
Interface	9-bit Parallel Data (TTL)
Logic Voltage (VDD)	5.0 V (±0.25 V)
Backlight Voltage	300 Vrms (Typical)
Operating Current	8.0–16 mA (VDD)
Operating Temperature	-20°C ~ +70°C
Storage Temperature	-30°C ~ +80°C
Controller	Built-in
Touch Screen	Without
RoHS	Compliant

Typical Applications

Industrial Control & Automation
- Injection Molding Machines：Haitian and other brands use this model for parameter display and operation interface.
- PLC & HMI Panels：Factory automation, production line monitoring, equipment control terminals.
- CNC Machine Tools：Display machining data, coordinates, and system status.
Medical Equipment
- Patient monitors, blood analyzers, medical instruments requiring stable display in harsh environments.
Embedded & Instrumentation
- Test & Measurement Instruments：Oscilloscopes, data loggers, industrial meters.
- Marine & Vehicle Terminals：On-board displays, ship control panels (wide temp, anti-vibration).
Legacy System Replacement
- Direct replacement for old 5.7" FSTN/STN modules in industrial devices, compatible with existing 9-bit parallel interfaces.
