HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial

SKU: HSD190MEN3
Model: HSD190MEN3
Diagonal Size: 19.0 inch
Panel Type: a-Si TFT-LCD, Transmissive, TN
Resolution: 1280 × 1024 (SXGA, 5:4)
Pixel Arrangement: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$93.00 $90.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
1/1
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
  • Description
HSD190MEN3 HannStar 19 inch 1280×1024 LCD Dispaly Panel For Industrial
Parameter Details
Model HSD190MEN3 (suffix: A00/A01/A02/A03/C00)
Diagonal Size 19.0 inch
Panel Type a-Si TFT-LCD, Transmissive, TN
Resolution 1280 × 1024 (SXGA, 5:4)
Pixel Arrangement RGB Vertical Stripe
Active Area 376.32 (W) × 301.056 (H) mm
Outline Dimensions 396 (W) × 324 (H) × 16/17 (D) mm
Brightness 300 cd/m² (Typ., A00/A03); 280 cd/m² (C00)
Contrast Ratio 1000:1 (Typ.)
Viewing Angle (CR≥10) 85°/85°/80°/80° (L/R/U/D)
Response Time 1.2 ms (Tr) / 3.8 ms (Td)
Display Colors 16.7M, 73% NTSC
Backlight 4 × CCFL, 40,000 hrs lifetime, no driver
Interface LVDS (2 ch 8-bit), 30-pin connector
Input Voltage 5.0 V (Typ.)
Surface Treatment Matte, Hard Coating (3H)
Weight 1.95 kg (A00/A03); 2.25 kg (C00/A02)
Operating Temperature 0 °C ~ +50 °C
Storage Temperature -20 °C ~ +60 °C
RoHS Compliant

Typical Applications

  • Industrial Control Monitors
    Factory automation, HMI, PLC workstations, and production line monitoring (stable 0~50°C operation)
  • Desktop & Commercial Displays
    Standard 19-inch office monitors, POS terminals, and retail display systems
  • Medical Equipment
    Non-critical diagnostic devices, patient monitoring systems, and medical imaging auxiliary displays
  • Kiosks & Self-Service Terminals
    ATMs, ticketing machines, and information kiosks (matte surface reduces glare)
  • Embedded & Rugged Systems
    Industrial PCs, marine displays, and factory floor terminals (wide viewing angle)
