| Model Number |
KCG057QV1DB-G62 |
| Brand |
KYOCERA / KOE Industrial CSTN-LCD LCM |
| Diagonal Size |
5.7 Inch Landscape |
| Native Resolution |
320(RGB) × 240 QVGA, Classic 4:3 Aspect Ratio, 70 PPI |
| Panel Technology |
Color Super-Twisted Nematic (CSTN), Normally Black Transmissive |
| Dot Layout |
RGB Vertical Stripe Pixel Arrangement |
| Backlight |
Single Side-entry CCFL Cold Cathode Lamp, Lifespan ≥50,000 Hours |
| Typical Brightness |
350 cd/m² |
| Typical Contrast Ratio |
55:1 (TM Transmission Mode) |
| Viewing Angle L/R/U/D (CR≥2) |
50° / 50° / 20° / 35° |
| View Direction |
6 O’Clock (Downward Optimal View) |
| Refresh Rate |
75Hz Standard Industrial Frequency |
| Response Time Tr/Td |
190ms / 180ms Typical |
| Color Performance |
Basic Full Color Display, 33% NTSC Color Gamut |
| Signal Interface |
Single Channel 8-bit Parallel Data, 20Pin FPC Connector |
| Logic Supply Voltage |
3.3V / 5.0V Dual Industrial Standard Input |
| Active Display Area |
115.18 (W) × 86.38 (H) mm |
| Overall Outline Dimension |
144 (W) × 104.8 (H) × 13.2 (T) mm |
| Net Weight |
Approx 175g |
| Surface Treatment |
Matte Anti-Glare Hard Coating, Anti-scratch |
| Touch Function |
Without Touch Digitizer (4-wire resistive touch glass optional) |
| Operating Temperature |
0℃ ~ +70℃ |
| Storage Temperature |
-20℃ ~ +60℃ |
| RoHS Compliance |
Lead-Free RoHS Standard |
| Production Status |
Discontinued Legacy Replacement Stock |
| Quality Grade |
Original New Grade A, Full Function & Aging Pixel Tested Before Shipment |
