KYOCERA NEW 5.7 inch LCD Display Panel KCG057QV1DL-G770 for Industrial
| Category |
Parameter |
Specification |
| General Info |
Panel Brand |
KYOCERA |
|
Panel Model |
KCG057QV1DL-G770 |
|
Screen Size |
5.7 inches |
|
Panel Type |
CSTN-LCD, LCM |
| Structure |
Resolution |
320(RGB) × 240 (QVGA) |
|
Pixel Arrangement |
RGB Vertical Stripe |
|
Display Area |
115.2(W) × 86.4(H) mm |
|
Outline Dimension |
144(W) × 104.8(H) × 13.2(Thick) mm |
| Optical |
Optical Mode |
STN, Normally Black, Transmissive |
|
Luminance |
380 cd/m² (Typ.) |
|
Contrast Ratio |
40:1 (Typ.) (Transmissive) |
|
Display Colors |
Pseudo Color |
| Backlight |
Lamp Type |
1 pcs CCFL |
|
LED Lifetime |
75,000 Hours |
| Electrical |
Signal Interface |
Parallel Data (1 ch, 8-bit), 20 pins, Terminal |
|
Panel Voltage |
3.3 / 5.0 V (Typ.) (VDD) |
| Environment |
Operating Temp. |
0 ~ 60 °C |
|
Storage Temp. |
-20 ~ 60 °C |
- Industrial Equipment: Widely used as display screens for CNC system computers, such as Japanese FANUC, German Siemens, Japanese Mitsubishi, KND, and Guangzhou CNC systems.
- Medical Instruments: Integrated into various medical diagnostic and monitoring devices.
- Automotive Navigation: Utilized in vehicle navigation and display systems.
- Monitoring Equipment: Applied in security and surveillance display terminals.
- Handheld PDAs: Used in portable data collectors and personal digital assistants.
- Self-service Terminals: Deployed in automated service kiosks and interactive machines.
KYOCERA
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
