| Brand | Kyocera |
|---|---|
| Model P/N | KCS057QV1AJ-G20 |
| Diagonal Size | 5.7" |
| Panel Type | CSTN-LCD, LCM |
| Resolution | 320(RGB)×240, QVGA 70PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 115.2(W)×86.4(H) mm |
| Bezel Opening | 120.2(W)×91.4(H) mm |
| Outline Size | 154.6(W)×114.8(H) ×9(D) mm |
| Surface | Glare (Haze 0%) |
| Brightness | 200 cd/m² (Typ.) |
| Contrast Ratio | 40:1 (Typ.) (TM) |
| Viewing Angle | 50/50/30/30 (Typ.)(CR≥2) |
| Display Mode | STN, Normally Black, Transmissive |
| Response Time | 220/110 (Typ.)(Tr/Td) |
| Display Colors | Color |
| Lamp Type | 1 pcs CCFL, 40K hours, Optional |
| Frequency | 75Hz |
| Touch Screen | Without |
| Panel Weight | 200g (Typ.) |
| Signal Interface | Parallel Data (1ch, 8-bit), 15 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 60 °C; Storage Temp.: -20 ~ 60 °C |
The KCS057QV1AJ-G20 delivers targeted value across several key industrial sectors . It is specifically recommended for industrial applications such as Human-Machine Interfaces (HMI) for factory automation, CNC machines, and process controllers . It is also well-suited for test and measurement instruments and non-diagnostic medical monitoring equipment where proven reliability and long product availability are essential .
