KOE SP14N02L6ALCZ 5.1 Inch 240×128 FSTN Monochrome Industrial LCD Display Module
The SP14N02L6ALCZ is a genuine 5.1-inch industrial-grade FSTN LCD display module manufactured by KOE (formerly Kyocera Display), a global leader in high-reliability industrial display solutions. Designed for long-term stable operation in harsh industrial environments, this monochrome graphic display features a 240×128 pixel resolution, 20-pin 8-bit parallel interface, and native compatibility with mainstream industrial control systems.
With over 15 years of professional experience in industrial display supply and equipment retrofit, TSS Service provides 100% original, factory-specification KOE display modules. This SP14N02L6ALCZ is a perfect drop-in replacement for aging or damaged industrial screens, eliminating the need for hardware or firmware modifications, restoring full visual functionality, and extending the service life of your critical industrial equipment.
| Technical Parameter |
Specification Details |
| Manufacturer |
KOE (Kyocera Display Corporation) |
| Official Part Number |
SP14N02L6ALCZ (Revision A) |
| Panel Type |
FSTN-LCD LCM (Liquid Crystal Module) |
| Display Size |
5.1 Inch (Diagonal) |
| Native Resolution |
240 (H) × 128 (V) Pixels |
| Aspect Ratio |
17:9 (H:V) |
| Pixel Pitch |
0.50mm × 0.50mm (H×V) |
| Active Display Area |
119.97mm × 63.97mm (H×V) |
| Bezel Opening Dimension |
124.0mm × 70.0mm (H×V) |
| Overall Outline Dimension |
159.4mm × 101.0mm (H×V) |
| Display Mode |
Transmissive Negative (Black/White Monochrome) STN |
| Typical Brightness |
150 cd/m² |
| Typical Contrast Ratio |
20:1 (TM) |
| Typical Response Time |
160ms (Rise Tr) / 110ms (Fall Td) |
| Typical Viewing Angle |
40° (CR≥2, Φ2-Φ1) |
| Backlight Type |
Integrated WLED (White LED) |
| Backlight Lifespan |
50,000 Hours (Typ.), No External Driver Required |
| Signal Interface |
20-Pin 8-Bit Parallel Interface (Pad) |
| Touch Screen |
Not Integrated |
| Typical Input Voltage |
5.0V DC |
| Operating Temperature Range |
0°C ~ 50°C (Commercial Industrial Grade) |
| Storage Temperature Range |
-20°C ~ 60°C |
| Country of Origin |
Taiwan, China |
Genuine KOE Factory-Specification Drop-In Design
This SP14N02L6ALCZ module strictly adheres to KOE's original manufacturing standards, ensuring 100% dimensional, electrical, and functional compatibility with the original equipment. It is a direct replacement for existing SP14N02L6ALCZ displays, no hardware or firmware changes required, greatly reducing equipment downtime during replacement and retrofit.
High-Reliability FSTN Display Technology
Equipped with advanced FSTN (Film Super Twisted Nematic) LCD technology, with a transmissive negative black/white monochrome display mode, this module delivers stable 20:1 typical contrast and wide viewing angles, even in variable industrial lighting conditions. The monochrome graphic architecture ensures long-term stable performance with no color shift or screen burn-in, fully suitable for 24/7 uninterrupted operation in industrial scenarios.
Rugged Industrial Environmental Adaptability
Engineered to withstand the rigors of industrial use, the SP14N02L6ALCZ offers an operating temperature range of 0°C to 50°C, a storage temperature range of -20°C to 60°C, and robust mechanical resistance to vibration, dust, and temperature fluctuations. It can maintain stable performance in factory automation, process control, and field instrumentation environments that are unfriendly to consumer-grade displays.
Optimized Electrical & Interface Compatibility
With a standard 20-pin 8-bit parallel interface and 5.0V typical input voltage, this module is natively compatible with most industrial control motherboards, PLC systems, and embedded devices. The integrated WLED backlight has a typical lifespan of 50,000 hours, no external driver required, ensuring long service life with minimal maintenance.
This KOE SP14N02L6ALCZ industrial LCD module is purpose-built for demanding industrial and embedded applications, including but not limited to:
- Factory Automation Control Panels & HMI (Human-Machine Interface) Systems
- Industrial Process Control Instrumentation & Monitoring Equipment
- Rugged Handheld Industrial Test & Measurement Devices
- PLC (Programmable Logic Controller) Operator Interfaces
- Industrial Weighing & Metering Equipment
- Medical & Laboratory Instrumentation Displays
- Legacy Industrial Equipment Screen Replacement & Retrofit Projects
Frequently Asked Questions (FAQs)
Q1: Is the KOE SP14N02L6ALCZ a direct drop-in replacement for my existing SP14N02L6ALCZ Rev A display?
A: Yes. This SP14N02L6ALCZ module strictly follows KOE's original factory specifications for Revision A, with 100% full compatibility in outline dimensions, mounting holes, 20-pin interface, electrical parameters, and display performance. It is a true plug-and-play drop-in replacement, no hardware modifications, firmware adjustments, or re-wiring are required. With over 15 years of industrial display retrofit experience, our engineering team can also provide pre-purchase compatibility verification to ensure a perfect fit for your equipment.
Q2: What interface does the SP14N02L6ALCZ LCD module use?
A: The KOE SP14N02L6ALCZ is equipped with a standard 20-pin 8-bit parallel interface (Pad type), with a typical 5.0V DC input voltage. This interface is natively compatible with most mainstream industrial control motherboards, PLC systems, HMI devices, and embedded industrial equipment. We can provide the original KOE official pinout definition and wiring guide upon request to support your integration and replacement work.
Q3: Does the SP14N02L6ALCZ include an integrated backlight, and what is its lifespan?
A: Yes, the SP14N02L6ALCZ has a built-in high-reliability WLED (White LED) backlight, with a typical service life of 50,000 hours. No external backlight driver is required, which simplifies integration and reduces later maintenance costs. The backlight is optimized for 24/7 uninterrupted operation in industrial scenarios, with stable brightness performance throughout its service life.
Q4: What is the operating temperature range of the KOE SP14N02L6ALCZ?
A: The SP14N02L6ALCZ has an industrial-grade operating temperature range of 0°C ~ 50°C, and a storage temperature range of -20°C ~ 60°C. Its rugged construction is engineered to withstand common industrial stressors including vibration, temperature fluctuations, and dust, making it suitable for long-term stable operation in factory automation, process control workshops, and indoor industrial environments.
Q5: Is the SP14N02L6ALCZ supplied by TSS Service a genuine KOE product?
A: Yes. All SP14N02L6ALCZ modules we supply are 100% genuine original KOE products, sourced from official authorized supply chains, with full traceability of manufacturing batches and production information. We have been specializing in industrial display solutions for more than 15 years, and we never sell refurbished, counterfeit, or inferior substitute products. Every module is fully tested before shipment, and comes with a standard 12-month warranty for manufacturing defects.
Q6: What is the resolution and display type of the SP14N02L6ALCZ?
A: The KOE SP14N02L6ALCZ is a 5.1-inch monochrome graphic industrial LCD display, with a native resolution of 240 (H) × 128 (V) pixels. It adopts FSTN (Film Super Twisted Nematic) LCD technology, with a transmissive negative (black/white) display mode, a typical contrast ratio of 20:1, and a wide viewing angle. Unlike color displays, this monochrome module has no screen burn-in risk, and can maintain stable display performance for long-term non-stop operation.
Q7: Can I get the full official datasheet for the SP14N02L6ALCZ before purchase?
A: Absolutely. We can provide the complete original KOE official datasheet, including detailed specifications, pinout definitions, mechanical dimensions, electrical characteristics, and integration guidelines for the SP14N02L6ALCZ. You can contact our technical support team at any time to get the full technical documents, and our in-house engineers can also provide free professional selection guidance and replacement compatibility assessment.
Q8: What applications is the KOE SP14N02L6ALCZ suitable for?
A: This industrial-grade LCD module is purpose-built for demanding industrial and embedded applications, including but not limited to: factory automation HMI control panels, PLC operator interfaces, industrial process control instrumentation, rugged handheld test & measurement devices, industrial weighing & metering equipment, medical laboratory instrumentation, and legacy industrial equipment screen retrofit & replacement projects.
Q9: What is the lead time and shipping policy for the SP14N02L6ALCZ?
A: The KOE SP14N02L6ALCZ is in stock and available for immediate shipment. Orders will be dispatched within 1-2 working days after payment is confirmed. We provide global shipping services with full logistics tracking, with a standard international shipping fee of $28.00. Expedited shipping options are also available upon request. You can contact our customer service team to confirm real-time inventory and shipping details before placing an order.
Q10: Are there compatible alternative models for the KOE SP14N02L6ALCZ?
A: We prioritize supplying the original SP14N02L6ALCZ model to ensure 100% drop-in compatibility and zero retrofit risk for your equipment. If you need an alternative solution due to special requirements or inventory constraints, our professional industrial display engineering team can provide verified alternative models with the same size, resolution, interface, and electrical parameters, and provide full technical support to ensure normal operation of your equipment.
