| Parameter | Specification |
|---|---|
| Display Size | 8.4 inches |
| Active Area | 170.496(W)×127.872(H) mm |
| Resolution | 1024 (H) × 768 (V) pixels |
| Display Type | a-Si TFT LCD, Transmissive |
| Viewing Angle | Wide Viewing Angle (e.g., IPS) |
| Brightness | 920 cd/m² (Typ.) |
| Contrast Ratio | 1100:1 (Typ.) (TM) |
| Color Depth | 16.7M colors |
| Surface Treatment | Anti-Glare Hard Coating |
| Interface | LVDS (1 ch, 8-bit) , 60 pins FPC |
| Power Supply | 1.8/3.3/13.0/-11V (Typ.)(IOVCC/VDD/AVDD/VGL) |
| Operating Temp. | -40 ~ 75 °C |
| Storage Temp. | -40 ~ 95 °C |
| Typical Applications | Industrial HMI, Medical Monitors, Test & Measurement Equipment, Portable Devices, Kiosks, Automotive (non-infotainment) |
Typical Applications:
Industrial Control & Automation: Human-Machine Interface (HMI) panels, PLC operator terminals, factory floor monitors.
Medical Equipment: Patient monitoring displays, diagnostic imaging consoles, portable medical devices.
Test & Measurement: Oscilloscopes, spectrum analyzers, field service equipment.
Transportation & Avionics: Dashboard displays, control system status panels.
Point-of-Sale & Kiosks: Self-service terminals, information displays.
