Panda 21.5 inch LC215DTBA 1920×1080 a-Si TFT-LCD, CELL

Name: Panda 21.5 inch LC215DTBA 1920×1080 a-Si TFT-LCD, CELL
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LC215DTBA
Price: 128 USD
Availability: InStock

SKU: LC215DTBA

Model Name: LC215DTBA
Display Size: 21.5"
Panel Type: a-Si TFT-LCD, CELL (FOB)
Resolution: 1920(RGB)×1080 (FHD), 16:9 aspect ratio
Pixel Format: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$130.00~~ $128.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Panda 21.5 inch LC215DTBA 1920×1080 a-Si TFT-LCD, CELL

Parameter	Specification
Manufacturer	PANDA
Model Name	LC215DTBA
Display Size	21.5"
Panel Type	a-Si TFT-LCD, CELL (FOB)
Resolution	1920(RGB)×1080 (FHD), 16:9 aspect ratio
Pixel Format	RGB Vertical Stripe
Display Area	476.64(W) × 268.11(H) mm
Outline Dimension	487.54(W) × 282.91(H) × 1.83(D) mm
Panel Weight	570g (Typ.)
Glass Depth	0.70 + 0.70 mm
Brightness	0 cd/m² (Cell, no backlight)
Contrast Ratio	1000:1 (Typ., TM)
Display Mode	TN, Normally White, Transmissive
Viewing Angle	85°/85°/80°/80° (Typ., CR≥10)
View Direction	6 o'clock
Response Time	5 ms (Typ., Tr+Td)
Transmissivity	5.45% (Typ., with polarizer)
Display Colors	16.7M, 72% NTSC
Frequency	75Hz
Surface Treatment	Antiglare, Hard coating (3H)
Driver IC	COF Built-in 6 source + 3 gate chips
Interface	LVDS (2 channel, 8-bit), 30-pin connector
Input Voltage	5.0V (Typ.)
Touch Screen	Without touch
Operating Temperature	0 ~ 50 °C
Storage Temperature	-20 ~ 60 °C
RoHS Compliance	Yes
