KYOCERA NEW 7.0 inch LCD Display Panel TCG070WVLQEPNN-SN21-S for Industrial
| Parameter |
Specification |
| Brand |
Tianma / NLT Technologies |
| Model |
TCG070WVLQEPNN-SN21-S |
| Display Type |
a-Si TFT-LCD, Normally Black |
| Screen Size |
7.0 inch |
| Resolution |
800 × 480 (WVGA) |
| Aspect Ratio |
15:9 (Wide format) |
| Outline Dimensions |
Approx. 164.9 × 100.0 × 5.3 mm (H×V×D) |
| Active Area |
154.08 × 85.92 mm (H×V) |
| Brightness |
700 ~ 1000 cd/m² (High Brightness / Sunlight Readable) |
| Contrast Ratio |
700:1 ~ 1000:1 (Typ.) |
| Viewing Angle |
85/85/85/85 (Up/Down/Left/Right) |
| Backlight |
WLED (White LED with integrated driver) |
| Interface |
LVDS (1 channel, 6-bit or 8-bit color depth) |
| Operating Temperature |
-30°C to +85°C (Industrial Wide Temp) |
| Touch Panel |
Optional Capacitive or Resistive Touch (depending on exact sub-variant) |
- Automotive & Transportation: Integrated into vehicle dashboards, rear-seat entertainment systems, commercial fleet management terminals, and heavy-duty vehicle displays due to its excellent vibration resistance and wide operating temperatures.
- Industrial Automation & HMI: Perfect for Human-Machine Interface panels, factory automation controllers, and robotics interfaces where clear visibility of complex graphics and real-time data is required.
- Outdoor Kiosks & ATMs: Used in self-service terminals, ticket vending machines, and outdoor information kiosks that are frequently exposed to direct sunlight.
- Marine Electronics: Applied in fish finders, GPS chartplotters, and boat navigation systems thanks to its high contrast and sunlight readability.
- Medical Equipment: Ideal for portable diagnostic devices, handheld patient monitoring units, and other medical instrumentation requiring reliable and sharp displays.
