NL8060BC31-47E 12.1'' 800(RGB)×600, SVGA LCD PANEL

SKU: NL8060BC31-47E
Model P/N:NL8060BC31-47E
Diagonal Size:12.1"
Panel Type:a-Si TFT-LCD, LCM
Resolution:800(RGB)×600, SVGA  82PPI
Pixel Format:RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$105.00 $100.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • NL8060BC31-47E 12.1'' 800(RGB)×600, SVGA LCD PANEL
  • NL8060BC31-47E 12.1'' 800(RGB)×600, SVGA LCD PANEL
1/1
  • NL8060BC31-47E 12.1'' 800(RGB)×600, SVGA LCD PANEL
  • Description

The NL8060BC31-47E is a robust and reliable 12.1-inch color TFT-LCD module, designed for industrial and embedded applications requiring a durable, medium-resolution display. It offers excellent readability and a proven design suitable for long-term system integration.

Feature Category Specification
Model NL8060BC31-47E
Display Size 12.1 inches (diagonal)
Display Type a-Si TFT Color LCD
Resolution 800 (RGB) × 600 pixels (SVGA)
Pixel Format 4:3 Aspect Ratio
Active Area (W×H) 246.0 mm × 184.5 mm (typical)
Module Dimensions 280(H)×210(V) mm
Display Mode Normally White, Transmissive
Interface LVDS (1 ch, 6/8-bit)
Surface Treatment Antireflection
Backlight Type WLED
Brightness (Typical) 300 cd/m² (or higher)
Key Characteristics High Reliability, Industrial Temperature Range, Long-term Availability, Robust Construction.

Target Applications

This module is a classic choice for demanding applications where durability and long-term supply are critical:

  • Industrial Human-Machine Interface (HMI) Panels

  • Factory Automation & Control Systems

  • Test & Measurement Equipment

  • Medical Diagnostic Devices & Monitors

  • Point-of-Sale (POS) / Kiosk Systems

  • Transportation & Marine Information Displays

  • Legacy System Upgrades
