PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial

SKU: PM070WX9
Model: PM070WX9
Diagonal Size    7.0 inch
Display Type    a-Si TFT-LCD, Transmissive, TN Normally White
Native Resolution    800 × 480 (WVGA, 16:9)
0.0 (0 Reviews)
0 Sold
$133.00 $130.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
1/1
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
  • Description
PVI 7 inch 800×480 LCD Panel Display PM070WX9 for Industrial
Parameter Specification
Brand PVI (Prime View International)
Model PM070WX9
Diagonal Size 7.0 inch
Display Type a-Si TFT-LCD, Transmissive, TN Normally White
Native Resolution 800 × 480 (WVGA, 16:9)
Active Display Area 152.4 mm (W) × 91.44 mm (H)
Outline Dimension 165 mm (W) × 104 mm (H) × 6.5 mm (D)
Pixel Pitch 0.190 mm × 0.190 mm
Brightness 950 cd/m² (Typ.)
Contrast Ratio 600:1 (Typ.)
Viewing Angle 75°/75°/50°/70° (L/R/U/D, CR≥10)
Color Depth 262K colors, 6-bit
Backlight WLED (3S6P), no driver, 50,000 hours lifetime
Interface 60-pin TTL (1 channel, 6-bit) FPC
Touch Panel Without touch
Surface Treatment Matte (anti-glare)
Operating Temperature -30℃ ~ +70℃
Storage Temperature -40℃ ~ +85℃
Supply Voltage 3.3V / 3.3V / 9.5V / 17.0V / -8.0V (VCC/VDD1/VDD2/VGG/VEE)
Net Weight 156 ± 10g
Production Status Discontinued

Typical Applications (English)

  • Outdoor industrial displays and sunlight-readable terminals
  • Industrial HMI, control panels and factory automation equipment
  • Transportation displays: railway, vehicle and marine monitoring systems
  • Medical devices requiring high brightness and wide temperature range
  • Smart home appliances and high-brightness consumer display products
  • Industrial panel PCs, embedded systems and 24/7 operation kiosks
