BOE NEW 15.6 inch LCD Display Panel NV156FHM-N6E for Laptop
| Parameter |
Specification |
| Model Number |
NV156FHM-N6E |
| Manufacturer |
BOE |
| Panel Size |
15.6 inch |
| Resolution |
1920(RGB) × 1080 (FHD) |
| Display Mode |
IPS, Normally Black, Transmissive |
| Pixel Arrangement |
RGB Vertical Stripe |
| Aspect Ratio |
16:9 (W:H) |
| Display Area |
344.16 (W) × 193.59 (H) mm |
| Outline Dimensions |
358.6 (W) × 218.6 (H) × 2.55 (D) mm (Max.) |
| Surface Treatment |
Haze (Anti-glare) |
| Backlight |
WLED, Side Light (Bottom) |
| Brightness |
300 cd/m² (Typ.) |
| Contrast Ratio |
700:1 (Typ.) |
| Display Colors |
16.7M (6-bit + Hi-FRC) |
| Signal Interface |
eDP (2 Lanes), HBR (2.7G/lane) |
| Operating Temperature |
0 ~ 50 °C |
| Storage Temperature |
-20 ~ 60 °C |
| Weight |
195g (Typ.) |
| Touch Panel |
No |
The NV156FHM-N6E is a standard component widely used in the consumer electronics sector. Its balance of resolution, size, and power efficiency makes it suitable for:
- Laptop Computers: This is the primary application for the module. Its 15.6-inch form factor and Full HD resolution make it a standard choice for mainstream laptops, providing clear visuals for general productivity, web browsing, and media consumption.
- Portable Monitors: The slim profile and standard eDP interface allow it to be easily integrated into portable external monitors used by professionals and gamers on the go.
- All-in-One PCs: The module's reliability and standard dimensions make it suitable for integration into compact All-in-One (AIO) desktop computers where space-saving design is essential.
- Industrial & Medical Displays: While primarily a consumer panel, its stable performance within the 0-50°C range allows for use in indoor industrial control panels or medical cart displays that do not require extreme temperature tolerance.
