Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial

SKU: TCG057QVLCSAFC-GA20
Model: TCG057QVLCSAFC-GA20
Brand: Kyocera
Diagonal Size: 5.7 inch
Resolution: 320 × 240(QVGA)
Display Type: Transmissive Color TFT, TN
0.0 (0 Reviews)
0 Sold
$133.00 $130.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
1/1
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
  • Description
Kyocera 5.7 inch LCD Display Screen TCG057QVLCSAFC-GA20 For Industrial
Parameter Description
Model TCG057QVLCSAFC-GA20
Brand Kyocera
Diagonal Size 5.7 inch
Resolution 320 × 240(QVGA)
Display Type Transmissive Color TFT, TN(Normally White)
Backlight WLED, 50,000+ hours lifetime
Brightness 1000 cd/m²(Typ.)
Contrast Ratio 500:1(Typ.)
Viewing Angle 80°/80°/80°/80°(L/R/U/D, CR≥5)
Interface CMOS(Parallel RGB, 18‑bit, 33‑pin connector)
Power Supply 3.3V(Typ.)
Operating Temperature -20°C ~ +70°C
Storage Temperature -30°C ~ +80°C
Outline Dimensions 127.2 × 100.4 × 5.7 mm
Active Area 115.2 × 86.4 mm
Dot Pitch 0.12 × 0.36 mm
Weight 130 g
Compliance RoHS

Applications(English)

  • Industrial HMI & Control Panels: Factory automation, PLC interfaces, CNC machinery, and industrial monitors.
  • Outdoor & Semi‑Outdoor Equipment: Solar‑powered terminals, outdoor kiosks, and marine navigation displays(high brightness for sunlight readability).
  • Medical Devices: Patient monitors, diagnostic equipment, and laboratory instruments(non‑imaging).
  • Vehicle‑Mounted Displays: Fleet management terminals, construction vehicle dashboards, and agricultural machinery displays.
  • Office & Commercial Automation: High‑end printers, copiers, and retail POS systems.
