TIANMA NEW 7.0 inch LCD Display Panel P0700WVN1MA00 for Industrial
| Parameter |
Specification |
| Model Number |
P0700WVN1MA00 |
| Manufacturer |
Tianma (TIANMA) |
| Panel Size |
7.0 inch |
| Resolution |
800(RGB) × 480 (WVGA) |
| Display Mode |
TN, Normally White, Transmissive |
| Pixel Arrangement |
RGB Vertical Stripe |
| Aspect Ratio |
16:9 (W:H) |
| Display Area |
154.08 (W) × 85.92 (H) mm |
| Outline Dimensions |
164.9 (W) × 100 (H) mm |
| Surface Treatment |
Haze (Anti-glare) |
| Backlight |
WLED, Side Light, No Driver |
| Brightness |
1000 cd/m² (Typ.) |
| Contrast Ratio |
1000:1 (Typ.) |
| Display Colors |
16.7M (8-bit) |
| Signal Interface |
TTL (1 channel, 8-bit) |
| Operating Temperature |
-30 ~ 85 °C |
| Storage Temperature |
-40 ~ 90 °C |
| Weight |
160g |
| Touch Panel |
No |
The P0700WVN1MA00 is engineered for robust performance in demanding environments. Its key features, such as high brightness, wide temperature tolerance, and vibration resistance, make it suitable for a range of applications:
- Industrial Control Systems: Its wide operating temperature range (-30 to 85 °C) and high vibration resistance (6.8G) make it ideal for human-machine interfaces (HMIs), factory automation equipment, and other industrial devices that require reliable operation in harsh conditions.
- Outdoor High-Brightness Displays: The high brightness of 1000 cd/m² ensures excellent readability even in direct sunlight, making it perfect for outdoor kiosks, information displays, and other applications exposed to strong ambient light.
- Automotive Electronics: The module's wide temperature range and durability are well-suited for integration into various in-vehicle electronic systems, such as dashboards, control panels, and infotainment systems.
