| Parameter | Value |
|---|---|
| Brand | Japan Display Inc. (formerly Hitachi) |
| Screen Size | 8.0 inches |
| Display Technology | IPS-Pro (In-Plane Switching), Normally Black Transmissive |
| Resolution | WVGA (800 x 480 pixels) |
| Aspect Ratio | 16:9 |
| Color Support | 262,144 colors (6-bit RGB) |
| Brightness | 600 cd/m² (typical) |
| Contrast Ratio | 600:1 (typical) |
| Viewing Angle | 170° horizontal / 170° vertical (or 176° in some descriptions) |
| Interface | CMOS (6-bit RGB) |
| Backlight | LED, with a long lifetime (70,000 hours) |
| Operating Temperature | -30°C to +80°C |
| Outline Dimensions | 190.0 (W) x 120.0 (H) x 12.8 (D) mm |
| Active Area | 174.0 (W) x 104.4 (H) mm |
| Pin Connector | 50 pins |
The TX20D26VM0AAA is engineered as a "Rugged+" display, designed to perform reliably in harsh conditions where standard displays would fail . Its wide temperature range, high brightness, and excellent viewing angles make it suitable for various demanding applications.
Industrial & Embedded Systems: Its primary market is industrial Human-Machine Interfaces (HMIs) and embedded systems. It is designed for equipment that requires a stable, high-quality GUI and consistent optical performance, even when viewed from an angle .
Outdoor and Kiosk Applications: With a brightness of 600 cd/m², this display is suitable for outdoor ticketing machines, information kiosks, and media terminals where the screen must remain readable in direct sunlight or bright ambient light .
Transportation (Marine, Aviation, Automotive): The wide operating temperature range (-30°C to 80°C) allows it to be used in vehicles and vessels. Specific uses include marine navigation systems, in-flight entertainment systems, and other on-board displays that face extreme temperature variations .
Specialty Medical Equipment: Its high reliability and consistent performance make it a candidate for portable or stationary medical devices used in various environments, from ambulances to clinics .
Home Automation & Building Controls: For high-end interior control systems or automation panels, the IPS-Pro technology ensures that the screen is clearly visible from anywhere in the room, maintaining color accuracy and contrast .
