KOE/JDI/HITACH 7.0 inch LCD Display Panel TX18D205VM0BPA for Industrial NEW
| Parameter |
Specification |
| Model Number |
TX18D205VM0BPA |
| Manufacturer |
KOE |
| Panel Type |
TFT-LCD (Thin Film Transistor) |
| Screen Size |
7.0 inches |
| Resolution |
800 (RGB) × 480 pixels (WVGA) |
| Aspect Ratio |
15:9 (Widescreen) |
| Active Area |
154.08 (W) × 85.92 (H) mm |
| Outline Dimensions |
165.0 (W) × 100.0 (H) × 4.8 (D) mm (Typical) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Display Mode |
Normally Black, Transmissive |
| Color Support |
16.7M (24-bit color) |
| Interface |
24-bit RGB Parallel Interface |
| Backlight Type |
LED (Light Emitting Diode) |
| Supply Voltage |
3.3V (Logic) / 12V or 24V (Backlight, varies by config) |
| Operating Temperature |
-20°C to 70°C (Wide Temperature) |
| Storage Temperature |
-30°C to 80°C |
KOE/JDI/HITACH
The TX18D205VM0BPA is engineered for applications requiring a compact, high-visibility display with a wide operating temperature range. Its specific applications include:
- Industrial Automation & Control:
- HMI (Human Machine Interface): Control panels for factory machinery, PLCs, and robotics.
- Instrumentation: Digital displays for testing equipment and measurement devices.
- Automotive & Transportation:
- In-Vehicle Displays: Used in dashboard clusters, rear-view monitor systems, and navigation units for cars, trucks, and agricultural vehicles.
- Telematics: On-board computer screens for fleet management.
- Medical Equipment:
- Patient monitoring systems and portable diagnostic devices requiring clear, stable visualization.
- Consumer & Commercial Electronics:
- Home Appliances: Control interfaces for high-end washing machines, refrigerators, or smart home hubs.
- Security Systems: Monitors for video intercoms and surveillance access control panels.
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
