BOE NEW 10.5 inch LCD Display Panel NV105WAM-N31 for Laptop, Pad & Tablet
| Parameter |
Specification |
| Model Number |
NV105WAM-N31 |
| Manufacturer |
BOE |
| Panel Size |
10.5 inch |
| Resolution |
1920(RGB) × 1280 (WUXGA) |
| Display Mode |
IPS, Normally Black, Transmissive |
| Pixel Arrangement |
RGB Vertical Stripe |
| Aspect Ratio |
3:2 (W:H) |
| Display Area |
216.72 (W) × 144.48 (H) mm |
| Outline Dimensions |
225.4 (W) × 155.1 (H) × 4.8 (D) mm (Max.) |
| Surface Treatment |
Haze (Anti-glare) |
| Backlight |
WLED, Side Light (Bottom) |
| Brightness |
500 cd/m² (Typ.) |
| Contrast Ratio |
1000:1 (Typ.) |
| Display Colors |
16.7M (6-bit + Hi-FRC) |
| Signal Interface |
eDP (2 Lanes), HBR (2.7G/lane) |
| Operating Temperature |
-20 ~ 70 °C |
| Storage Temperature |
-30 ~ 80 °C |
| Weight |
310g (Typ.) |
| Touch Panel |
No |
The NV105WAM-N31 is engineered for robust performance in demanding environments. Its key features, such as high brightness, wide temperature tolerance, and a 3:2 aspect ratio, make it suitable for a range of applications:
- Industrial Control Systems: Its wide operating temperature range (-20 to 70 °C) makes it ideal for human-machine interfaces (HMIs), factory automation equipment, and other industrial devices that require reliable operation in harsh conditions.
- Medical Equipment: The high brightness of 500 cd/m² and clear IPS display are well-suited for integration into various medical devices and diagnostic equipment that require reliable visual data presentation.
- Commercial & Retail Displays: The 10.5-inch form factor and high resolution are well-suited for digital signage, point-of-sale (POS) terminals, and information kiosks that benefit from a bright, high-definition screen.
- Portable Monitors: The module's slim profile and standard eDP interface allow it to be easily integrated into portable external monitors, often used as secondary displays for laptops or mobile devices.
BOE
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
