BOE NEW 15.6 inch LCD Display Panel NV156FHM-N4V for Laptop
| Parameter |
Specification |
| Model Number |
NV156FHM-N4V |
| Manufacturer |
BOE |
| Panel Size |
15.6 inch |
| Resolution |
1920(RGB) × 1080 (FHD) |
| Display Mode |
ADS (IPS), Normally Black, Transmissive |
| Pixel Arrangement |
RGB Vertical Stripe |
| Aspect Ratio |
16:9 (W:H) |
| Display Area |
344.16 (W) × 193.59 (H) mm |
| Outline Dimensions |
350.66 (W) × 216.15 (H) mm (Typ.) |
| Surface Treatment |
Haze (Anti-glare) |
| Backlight |
WLED, Side Light |
| Brightness |
300 cd/m² (Typ.) |
| Contrast Ratio |
700:1 (Typ.) |
| Display Colors |
16.7M (6-bit + Hi-FRC) |
| Signal Interface |
eDP (2 Lanes), HBR (2.7G/lane) |
| Operating Temperature |
0 ~ 50 °C |
| Storage Temperature |
-20 ~ 60 °C |
| Weight |
370g (Max.) |
| Touch Panel |
No |
The NV156FHM-N4V is engineered for applications requiring stable visual performance and high color accuracy. Its key features make it suitable for a range of professional and consumer uses:
- Laptop Computers: This is the primary application for the module. Its 15.6-inch form factor, FHD resolution, and wide viewing angles make it a standard choice for mainstream business laptops,轻薄 notebooks, and multimedia laptops, providing clear visuals for office work and entertainment.
- Industrial Control Systems: The module's stable performance within the 0-50°C range and reliable eDP interface make it suitable for integration into indoor industrial testing systems, automation control panels, and human-machine interfaces (HMIs).
- Commercial Display Solutions: The high color fidelity and anti-glare surface treatment are well-suited for digital signage, information kiosks, and other commercial display applications that benefit from a high-definition, readable screen in various lighting conditions.
- Medical Equipment: The clear display and stable performance are well-suited for integration into various medical devices and diagnostic equipment that require reliable visual data presentation.
BOE
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
