Ortustech NEW 5.0 inch LCD Display Panel COM50H5N17ULC for Industrial
| Parameter |
Specification |
| Model Number |
COM50H5N17ULC |
| Brand |
Ortustech |
| Panel Type |
a-Si TFT-LCD, Semi-Transflective (STN) |
| Display Size |
5.0 inch |
| Resolution |
800 × 480 (RGB), WVGA |
| Display Area |
109.20 × 65.52 mm |
| Outline Dimensions |
124.00 × 80.52 mm |
| Brightness |
400 cd/m² (Typ.) |
| Contrast Ratio |
900:1 (Typ.) [Transmissive] |
| Viewing Angle |
80/80/80/80 (Min.)(CR≥10) (L/R/U/D) |
| Response Time |
60/40 (Max.)(Tr/Td) ms |
| Color Support |
262K/16.7M colors (6-bit /8-bit) |
| Backlight Type |
WLED (50K Hours) |
| Interface |
LVDS (1 ch, 6/8-bit) |
| Supply Voltage |
3.3V (Typ.) |
| Operating Temp. |
-30 ~ 80 °C |
| Storage Temp. |
-40 ~ 90 °C |
This rugged, wide-temperature display is ideal for automotive and industrial environments where reliability and visibility are critical.
-
Automotive & Navigation:
- Car navigation systems and in-vehicle infotainment (IVI) displays.
- Dashboard instrumentation and cluster displays for commercial vehicles.
-
Industrial Control Systems:
- Used in CNC machines (e.g., FANUC, Siemens, Mitsubishi, KND, Guangzhou CNC) for operator interfaces and programming.
- HMIs (Human-Machine Interfaces) in factory automation and process control.
-
Medical Instruments:
- Portable diagnostic devices and patient monitoring terminals.
- Handheld medical testing equipment.
-
Outdoor & Harsh Environments:
- Outdoor digital signage and public information kiosks.
- Industrial equipment requiring operation in high-temperature conditions.
-
Handheld & Field Devices:
- Handheld PDAs and ruggedized data loggers.
- Field service tools and portable barcode scanners.
-
Self-service & Consumer Electronics:
- ATM machines and point-of-sale (POS) terminals.
- Digital signage kiosks and receipt printers.
Ortustech
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
